113 Tensioned Cosmopolitan (Over 12’ W)
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 44839 Screw for slat cap assy. 4 $0.27
2 98895 Slat cap assy. (includes #1) 2 $40.00
3 10685 Tab 24-44 $0.37
4 75658
Line, chalk and mason black (per foot). Figure one side at approximately height of fabric + 2' + any extra
needed.
Per size $0.23
5 Fabric and roller assemblies include #2, 3 and 4
HDTV (16:9) Format
12770 Fabric and roller assy.,Parallax Stratos 1.0 92" x 164" - 188" diag. 1 $3,240.00
22365 Fabric and roller assy., HD Progressive 0.9 92" x 164" - 188" diag. 1 $3,086.00
22366 Fabric and roller assy., HD Progressive 1.1 92" x 164" - 188" diag. 1 $3,086.00
99552 Fabric and roller assy., HD Progressive 1.1 Contrast 92" x 164" - 188" diag. 1 $3,086.00
29202 Fabric and roller assy., HD Progressive 1.3 92" x 164" - 188" diag. 1 $3,086.00
99554 Fabric and roller assy., HD Progressive ReView 0.9 92" x 164" - 188" diag. 1 $3,086.00
99548 Fabric and roller assy., Da-Mat 92" x 164" - 188" diag. 1 $2,543.00
99553 Fabric and roller assy., Da-Tex 92" x 164" - 188" diag. 1 $2,902.00
12771 Fabric and roller assy., Parallax Stratos 1.0 108" x 192" - 220" diag. 1 $3,840.00
22367 Fabric and roller assy., HD Progressive 0.9 108" x 192" - 220" diag. 1 $3,657.00
22368 Fabric and roller assy., HD Progressive 1.1 108" x 192" - 220" diag. 1 $3,657.00
99675 Fabric and roller assy., HD Progressive 1.1 Contrast 108" x 192" - 220" diag. 1 $3,657.00
29508 Fabric and roller assy., HD Progressive 1.3 108" x 192" - 220" diag. 1 $3,657.00
99677 Fabric and roller assy., HD Progressive ReView 0.9 108" x 192" - 220" diag. 1 $3,657.00
99671 Fabric and roller assy., Da-Mat 108" x 192" - 220" diag. 1 $3,013.00
99676 Fabric and roller assy., Da-Tex 108" x 192" - 220" diag. 1 $3,359.00
Wide (16:10) Format
12772 Fabric and roller assy., Parallax Stratos 1.0 100" x 160" - 189" diag. 1 $3,416.00
22369 Fabric and roller assy., HD Progressive 0.9 100" x 160" - 189" diag. 1 $3,253.00
22370 Fabric and roller assy., HD Progressive 1.1 100" x 160" - 189" diag. 1 $3,253.00
21089 Fabric and roller assy., HD Progressive 1.1 Contrast 100" x 160" - 189" diag. 1 $3,253.00
29203 Fabric and roller assy., HD Progressive 1.3 100" x 160" - 189" diag. 1 $3,253.00
21091 Fabric and roller assy., HD Progressive ReView 0.9 100" x 160" - 189" diag. 1 $3,253.00
21085 Fabric and roller assy., Da-Mat 100" x 160" - 189" diag. 1 $2,680.00
21090 Fabric and roller assy., Da-Tex 100" x 160" - 189" diag. 1 $2,962.00
12773 Fabric and roller assy., Parallax Stratos 1.0 110" x 176" - 208" diag. 1 $3,972.00
22371 Fabric and roller assy., HD Progressive 0.9 110" x 176" - 208" diag. 1 $3,783.00
22372 Fabric and roller assy., HD Progressive 1.1 110" x 176" - 208" diag. 1 $3,783.00
21096 Fabric and roller assy., HD Progressive 1.1 Contrast 110" x 176" - 208" diag. 1 $3,783.00
29509 Fabric and roller assy., HD Progressive 1.3 110" x 176" - 208" diag. 1 $3,783.00
21098 Fabric and roller assy., HD Progressive ReView 0.9 110" x 176" - 208" diag. 1 $3,783.00
21092 Fabric and roller assy., Da-Mat 110" x 176" - 208" diag. 1 $3,117.00
21097 Fabric and roller assy., Da-Tex 110" x 176" - 208" diag. 1 $3,480.00
12774 Fabric and roller assy., Parallax Stratos 1.0 120" x 192" - 226" diag. 1 $4,263.00
22373 Fabric and roller assy., HD Progressive 0.9 120" x 192" - 226" diag. 1 $4,060.00
22374 Fabric and roller assy., HD Progressive 1.1 120" x 192" - 226" diag. 1 $4,060.00
21103 Fabric and roller assy., HD Progressive 1.1 Contrast 120" x 192" - 226" diag. 1 $4,060.00
29510 Fabric and roller assy., HD Progressive 1.3 120" x 192" - 226" diag. 1 $4,060.00
21105 Fabric and roller assy., HD Progressive ReView 0.9 120" x 192" - 226" diag. 1 $4,060.00
21099 Fabric and roller assy., Da-Mat 120" x 192" - 226" diag. 1 $3,345.00
21104 Fabric and roller assy., Da-Tex 120" x 192" - 226" diag. 1 $3,731.00
