199 Model C E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 82998 Screw for pin end and spring end assembly for 3" roller 6 $0.16
2 80765 Roller plug for 1 3/4" roller (not shown) 1 $2.30
3 25736 Screw for end caps 10 $0.27
4 37238 Pin end cap, white plastic for screens with 1 3/4" roller (not shown) 1 $5.85
37246 Pin end cap, white plastic for screens with 3" roller 1 $5.85
5 78343 White case for 60" and 72" diag. screens 1 $48.30
78344 White case for 70" and 84" diag. screens 1 $52.80
33636WHITE White case for 72" screens 1 $55.80
78345 White case for 84", 100" diag., 92" diag. and 94" diag. screens with 3" roller (Prior to 2-8-19) 1 $63.70
78283 White case for 8', 120" diag., 106" diag. and 109" diag. screens with 3" roller (Prior to 2-8-19) 1 $71.30
12182 White case for 84", 100" diag., 92" diag. and 94" diag. screens with 1 3/4" roller (2-8-19 and later) 1 $63.70
12183 White case for 8', 120" diag., 106" diag. and 109" diag. screens with 1 3/4" roller (2-8-19 and later) 1 $71.30
94724 White case for 110" diag. and 113" diag. screens 1 $73.40
78312 White case for 9', 119" diag. and 123" diag. screens 1 $75.70
35021WHITE White case for 130" diag. screens 1 $76.90
78307 White case for 10', 150" diag., 133" diag. and 137" diag. screens 1 $80.00
78313 White case for 12', 180" diag. and 159" diag. screens 1 $92.10
92026 White case for 200" diag. screens 1 $94.40
6 37237 Spring end cap, white plastic for screens with 1 3/4" roller (not shown) 1 $5.85
37245 Spring end cap, white plastic for screens with 3" roller 1 $5.85
7 Roller assemblies include items #1, 2 (plug), and 12
93958 1 3/4" roller assy. for 60" and 72" diag. screens (not shown) 1 $39.50
93959 1 3/4" roller assy. for 70" and 84" diag. screens (not shown) 1 $41.90
33645 1 3/4" roller assy. for 72" screens (not shown) 1 $42.30
57707 3" roller Roller assy. for 84", 100" diag., 92" diag. and 94" diag. Screens (Prior to 2-8-19) 1 $155.00
57686 3" roller Roller assy. for 8', 120" diag., 106" diag. and 109" diag. screens (Prior to 2-8-19) 1 $160.00
93961 1 3/4" Roller assy. for 84", 100" diag., 92" diag. and 94" diag. Screens (2-8-19 and later) 1 $41.90
93962 1 3/4" Roller assy. for 8', 120" diag., 106" diag. and 109" diag. screens (2-8-19 and later) 1 $42.80
72403 Roller assy. for 110" diag. and 113" diag. screens 1 $161.00
57687 Roller assy. for 9', 119" diag. and 123" diag. screens 1 $163.00
35800 Roller assy. for 130" diag. screens 1 $167.00
57688 Roller assy. for 10', 150" diag., 133" diag. and 109" diag. screens 1 $166.00
57685 Roller assy. for 12', 180" diag., 159" diag. and 164" diag. screens 1 $172.00
92029 Roller assy. for 200" diag. screens 1 $175.00
8 44726 Screw for dog for 3" roller 1 $0.29
9 98223 Pawl (dog) for 3" roller 1 $1.50
10 57705 Plug and spear assy. for 3" roller (includes #8 and 9) 1 $31.50
11 45118 Plastic anchor for spring assy. for 3" roller 1 $2.65
12 93495 Spring assy. for 1 3/4" roller (not shown) 1 $28.10
57706 Spring assy. for 3" roller (includes #10 and 11) 1 $101.00
13 Screen Surface
HDTV (16:9) Format
84050 Fabric, Matte White 45" x 80" - 92" diag. (Prior to 2-8-19) 1 $213.00
92813 Fabric, High Contrast Matte White 45" x 80" - 92" diag. (Prior to 2-8-19) 1 $230.00
12184 Fabric, Matte White 45" x 80" - 92" diag. (2-8-19 and later) 1 $213.00
12185 Fabric, High Contrast Matte White 45" x 80" - 92" diag. (2-8-19 and later) 1 $230.00
78951 Fabric, Matte White 52" x 92" - 106" diag. (Prior to 2-8-19) 1 $294.00
92814 Fabric, High Contrast Matte White 52" x 92" - 106" diag. (Prior to 2-8-19) 1 $322.00
12187 Fabric, Matte White 52" x 92" - 106" diag. (2-8-19 and later) 1 $294.00
12188 Fabric, High Contrast Matte White 52" x 92" - 106" diag. (2-8-19 and later) 1 $322.00
