173
DL–0674 (Rev. 2) 07.21
© 2021 Legran AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
6 47491 Black cap for fabric 30-88 $0.37
7 47490 Heavy socket for fabric snaps of corners (not shown) 4 $0.37
8 47489 Light socket for all fabric snaps except corners (not shown) 26-84 $0.37
9 Fabric assemblies include #6 and 7
HDTV (16:9) Format
93283 Fabric assy., Da-Mat 37.5" x 67" - 77" diag. 1 $459.00
93285 Fabric assy., Da-Tex 37.5" x 67" - 77" diag. 1 $473.00
96882 Fabric assy., Da-Mat 40.5" x 72" - 82" diag. 1 $490.00
96884 Fabric assy., Da-Tex 40.5" x 72" - 82" diag. 1 $505.00
84057 Fabric assy., Da-Mat 45" x 80" - 92" diag. 1 $547.00
84058 Fabric assy., Da-Tex 45" x 80" - 92" diag. 1 $567.00
96802 Fabric assy., Da-Mat 49" x 87" - 100" HD diag. 1 $627.00
96804 Fabric assy., Da-Tex 49" x 87" - 100" HD diag. 1 $646.00
78979 Fabric assy., Da-Mat 52" x 92" - 106" diag. 1 $707.00
78980 Fabric assy., Da-Tex 52" x 92" - 106" diag. 1 $725.00
94774 Fabric assy., Da-Mat 54" x 96" - 110" diag. 1 $735.00
94776 Fabric assy., Da-Tex 54" x 96" - 110" diag. 1 $762.00
78983 Fabric assy., Da-Mat 58" x 104" - 119" diag. 1 $764.00
78984 Fabric assy., Da-Tex 58" x 104" - 119" diag. 1 $816.00
78987 Fabric assy., Da-Mat 65" x 116" - 133" diag. 1 $831.00
78988 Fabric assy., Da-Tex 65" x 116" - 133" diag. 1 $914.00
78991 Fabric assy., Da-Mat 78" x 139" - 159" diag. 1 $1,022.00
78992 Fabric assy., Da-Tex 78" x 139" - 159" diag. 1 $1,212.00
94055 Fabric assy., Da-Mat 94.5" x 168" - 193" diag. 1 $1,287.00
94057 Fabric assy., Da-Tex 94.5" x 168" - 193" diag. 1 $1,511.00
94062 Fabric assy., Da-Mat 108" x 192" - 220" diag. 1 $1,461.00
94064 Fabric assy., Da-Tex 108" x 192" - 220" diag. 1 $1,716.00
Video (4:3) Format
58739 Fabric assy., Da-Mat 41" x 56" - 72" diag. 1 $380.00
58760 Fabric assy., Da-Tex 41" x 56" - 72" diag. 1 $419.00
80259 Fabric assy., Da-Mat 50" x 67" - 84" diag. 1 $390.00
80255 Fabric assy., Da-Tex 50" x 67" - 84" diag. 1 $402.00
58740 Fabric assy., Da-Mat 59" x 80" - 100" diag. 1 $516.00
58761 Fabric assy., Da-Tex 59" x 80" - 100" diag. 1 $542.00
58741 Fabric assy., Da-Mat 68" x 92" - 120" diag. 1 $650.00
58762 Fabric assy., Da-Tex 68" x 92" - 120" diag. 1 $681.00
76934 Fabric assy., Da-Mat 90" x 120" - 150" diag. 1 $753.00
76935 Fabric assy., Da-Tex 90" x 120" - 150" diag. 1 $849.00
76937 Fabric assy., Da-Mat 108" x 144" - 180" diag. 1 $927.00
76938 Fabric assy., Da-Tex 108" x 144" - 180" diag. 1 $1,133.00
76940 Fabric assy., Da-Mat 120" x 160" - 200" diag. 1 $1,191.00
76941 Fabric assy., Da-Tex 120" x 160" - 200" diag. 1 $1,443.00
84159 Fabric assy., Da-Mat 144" x 192" - 240" diag. 1 $1,374.00
84160 Fabric assy., Da-Tex 144" x 192" - 240" diag. 1 $1,499.00
94140
Carton for 77" diag., 82" diag. 92" diag., 100" diag. HDTV, 106" diag., 110" diag., screens - longest tube length +
28"
Per foot $3.90
87014 Carton - for all other size screens - longest tube length + 5" Per foot $2.30
