Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) User Manual
Page 99
99
DL–0659 (Rev. 4) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
89579BLACK Cover, wire LVC screens (prior to 7-01-06), black
1
$5.00
25
37138
Roller bracket assy., pin end (prior to 7/16/07) (not shown)
1
$1.75
92383
Roller bracket assy., motor end for 10' x 10' and below screens
1
$25.00
28355
Roller bracket assy., motor end for over 10' x 10' screens (not shown)
1
$25.00
26
20612KIT
Motor assy., 120v for standard and SCB-100 screens with 3.25" rollers up to and including 10' x 10'
1
$390.00
20612SKIT
Motor assy., 120v Silent for standard and SCB-100 screens with 3.25" rollers up to and including 10' x 10'
1
$487.00
22291KIT
Motor assy., 120v for SCB-200 screens with 3.25" rollers up to and including 10' x 10'
1
$390.00
22291SKIT
Motor assy., 120v Silent for SCB-200 screens with 3.25" rollers up to and including 10' x 10'
1
$487.00
38890KIT
Motor assy., 120v for LVC and VPI screens with 3.25" rollers
1
$487.00
38890LSKIT Motor assy., 120v Silent for LVC and VPI screens with 3.25" rollers up to and including 10' x 10'
1
$585.00
37989KIT
Motor assy., 120v for standard and SCB-100 screens over 10' wide with 3.25" rollers
1
$390.00
37990KIT
Motor assy., 120v for SCB-200 screens over 10' wide with 3.25" rollers
1
$390.00
20614KIT
Motor assy., 240v for standard, VPI and SCB-100/200 screens with 3.25" rollers up to and including 10' x 10'
1
$390.00
20614SKIT
Motor assy., 240v Silent for standard, VPI and SCB-100/200 screens with 3.25" rollers up to and including
10' x 10'
1
$487.00
32645KIT
Motor assy., 240v for LVC screens with 3.25" rollers before 4/12/2018
1
$800.00
12147KIT
Motor assy., 240v for LVC screens with 3.25" rollers 4/12/2018 and after
1
$487.00
32645LSKIT Motor assy., 240v Silent for LVC screens with 3.25" rollers up to and including 10' x 10' before 6/11/2018
1
$585.00
12279KIT
Motor assy., 240v Silent for LVC screens with 3.25" rollers up to and including 10' x 10 '6/11/2018 and after
1
$585.00
32692KIT
Motor assy., 240v for standard, VPI and SCB-100 screens over 10' wide with 3.25" rollers
1
$390.00
32693KIT
Motor assy., 240v for SCB-200 screens over 10' wide with 3.25" rollers
1
$390.00
94785TABS Drive wheel/rubber mount for screens purchased before 1-22-04 (not shown)
1
$40.00
27
97290
Hair cotter pin, 5/16" - 3/8" x 1 5/8"
1
$0.47
28
38885
Built-in LVC motor hardware kit (not shown)
1
$298.00
99607
ILT/LVC motor hardware kit (not shown)
1
$120.00
38885B
Built-in motor hardware kit for case only (not shown)
1
$94.40
99607B
ILT/LVC motor hardware kit for case only (not shown)
1
$94.40
80575
Wall switch, 120v white (not shown)
1
$77.00
40961
Wall switch, 120v ivory (not shown)
1
$77.00
11147
Wall switch, 240v white double push putton (not shown)
1
$77.00
38463E
Wall switch, 240v white rocker (not shown)
1
$77.00
