Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) - Manual (Page 5)

5 Wireline Advantage Electrol E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
12 29377 Bolt for pin end bracket 3 $0.28
13 29352 End cap for pin end side of case 1 $48.00
14 35907 Screw to attach pin end side of case 8 $0.80
15 35888 Bracket for access door attachment 2 $7.80
16 80874 Nut to attach access door bracket 4 $0.32
17 44842 Washer to attach access door bracket 4 $0.35
18 44731 Bolt to attach access door bracket 4 $0.23
19 29305 White access door for 133" and 137" diagonal screens 1 $389.00
29259 White access door for 159" and 164" diagonal screens 1 $412.00
29398 White access door for 188" and 189" diagonal screens 1 $434.00
29416 White access door for 208" diagonal screens 1 $457.00
29384 White access door for 220" and 226" diagonal screens 1 $480.00
20 29382 Batten end cap for right side 1 $5.70
21 Fabric Assembly
HDTV (16:9) Format
12739 Fabric Assembly, Parallax Stratos 1.0 65" x 116" - 133" Diagonal 1 $2,397.00
29685 Fabric Assembly, HD Progressive 0.6 65" x 116" - 133" Diagonal 1 $2,283.00
29686 Fabric Assembly, HD Progressive 0.9 65" x 116" - 133" Diagonal 1 $2,283.00
29687 Fabric Assembly, HD Progressive 1.1 65" x 116" - 133" Diagonal 1 $2,283.00
12408 Fabric Assembly, HD Progressive 1.1 Contrast 65" x 116" - 133" Diagonal 1 $2,283.00
29688 Fabric Assembly, HD Progressive 1.3 65" x 116" - 133" Diagonal 1 $2,283.00
29689 Fabric Assembly, HD Progressive ReView 0.9 65" x 116" - 133" Diagonal 1 $2,168.00
12740 Fabric Assembly, Parallax Stratos 1.0 78" x 139" - 159" Diagonal 1 $2,517.00
29690 Fabric Assembly, HD Progressive 0.6 78" x 139" - 159" Diagonal 1 $2,397.00
29691 Fabric Assembly, HD Progressive 0.9 78" x 139" - 159" Diagonal 1 $2,397.00
29692 Fabric Assembly, HD Progressive 1.1 78" x 139" - 159" Diagonal 1 $2,397.00
12409 Fabric Assembly, HD Progressive 1.1 Contrast 78" x 139" - 159" Diagonal 1 $2,397.00
29693 Fabric Assembly, HD Progressive 1.3 78" x 139" - 159" Diagonal 1 $2,397.00
29694 Fabric Assembly, HD Progressive ReView 0.9 78" x 139" - 159" Diagonal 1 $2,276.00
12741 Fabric Assembly, Parallax Stratos 1.0 92" x 164" - 188" Diagonal 1 $2,756.00
29695 Fabric Assembly, HD Progressive 0.6 92" x 164" - 188" Diagonal 1 $2,625.00
29696 Fabric Assembly, HD Progressive 0.9 92" x 164" - 188" Diagonal 1 $2,625.00
29697 Fabric Assembly, HD Progressive 1.1 92" x 164" - 188" Diagonal 1 $2,625.00
12410 Fabric Assembly, HD Progressive 1.1 Contrast 92" x 164" - 188" Diagonal 1 $2,625.00
29698 Fabric Assembly, HD Progressive 1.3 92" x 164" - 188" Diagonal 1 $2,625.00
29699 Fabric Assembly, HD Progressive ReView 0.9 92" x 164" - 188" Diagonal 1 $2,493.00
12742 Fabric Assembly, Parallax Stratos 1.0 108" x 192" - 220" Diagonal 1 $3,115.00
29700 Fabric Assembly, HD Progressive 0.6 108" x 192" - 220" Diagonal 1 $2,967.00
29701 Fabric Assembly, HD Progressive 0.9 108" x 192" - 220" Diagonal 1 $2,967.00
29655 Fabric Assembly, HD Progressive 1.1 108" x 192" - 220" Diagonal 1 $2,967.00
12411 Fabric Assembly, HD Progressive 1.1 Contrast 108" x 192" - 220" Diagonal 1 $2,967.00
29702 Fabric Assembly, HD Progressive 1.3 108" x 192" - 220" Diagonal 1 $2,967.00
29703 Fabric Assembly, HD Progressive ReView 0.9 108" x 192" - 220" Diagonal 1 $2,818.00
Wide (16:10) Format
12743 Fabric Assembly, Parallax Stratos 1.0 72.5" x 116" - 137" Diagonal 1 $2,397.00
29704 Fabric Assembly, HD Progressive 0.6 72.5" x 116" - 137" Diagonal 1 $2,283.00
29705 Fabric Assembly, HD Progressive 0.9 72.5" x 116" - 137" Diagonal 1 $2,283.00
29706 Fabric Assembly, HD Progressive 1.1 72.5" x 116" - 137" Diagonal 1 $2,283.00
12412 Fabric Assembly, HD Progressive 1.1 Contrast 72.5" x 116" - 137" Diagonal 1 $2,283.00
29707 Fabric Assembly, HD Progressive 1.3 72.5" x 116" - 137" Diagonal 1 $2,283.00
29708 Fabric Assembly, HD Progressive ReView 0.9 72.5" x 116" - 137" Diagonal 1 $2,168.00
