Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) User Manual
Page 66
66
Tensioned Conference Electrol
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
22339
Fabric and roller assy., HD Progressive 0.9 65" x 104" - 123" diag.
1
$2,111.00
22340
Fabric and roller assy., HD Progressive 1.1 65" x 104" - 123" diag.
1
$2,111.00
21721
Fabric and roller assy., HD Progressive 1.1 Contrast 65" x 104" - 123" diag.
1
$2,111.00
29191
Fabric and roller assy., HD Progressive 1.3 65" x 104" - 123" diag.
1
$2,111.00
21717
Fabric and roller assy., Da-Mat 65" x 104" - 123" diag.
1
$1,752.00
22341
Fabric and roller assy., HD Progressive 0.9 69" x 110" - 130" diag.
1
$2,251.00
22342
Fabric and roller assy., HD Progressive 1.1 69" x 110" - 130" diag.
1
$2,251.00
34897
Fabric and roller assy., HD Progressive 1.1 Contrast 69" x 110" - 130" diag.
1
$2,251.00
29192
Fabric and roller assy., HD Progressive 1.3 69" x 110" - 130" diag.
1
$2,251.00
34893
Fabric and roller assy., Da-Mat 69" x 110" - 130" diag.
1
$1,868.00
22343
Fabric and roller assy., HD Progressive 0.9 72 1/2" x 116" - 137" diag.
1
$2,393.00
22344
Fabric and roller assy., HD Progressive 1.1 72 1/2" x 116" - 137" diag.
1
$2,393.00
21120
Fabric and roller assy., HD Progressive 1.1 Contrast 72 1/2" x 116" - 137" diag.
1
$2,393.00
29193
Fabric and roller assy., HD Progressive 1.3 72 1/2" x 116" - 137" diag.
1
$2,393.00
21116
Fabric and roller assy., Da-Mat 72 1/2" x 116" - 137" diag.
1
$1,986.00
6
22098
Camera shelf assy.
1
$105.00
7
72537
Screw to attach the cable clamp on the arm assy.
18-24
$0.32
8
22120
Cable clamp on the arm assy.
18-24
$0.59
Cable clamp on the camera shelf assy.
2
9
22127
Nut for cable clamp on the arm assy.
2
$0.13
10
22064PC
Case mounting bracket
2
$93.50
11
94082
Screw to attach junction box to the cover plate
3
$0.16
Screw to attach PCB, splitter and bracket assy.
2
12
22053
Junction box assy.
1
$46.70
13
32773
PCB, splitter and bracket assy., 120v
1
$410.00
14
22092
Cover plate, motor end
1
$11.70
15
22061PC
Trim, motor end
1
$457.00
16
22056
Fabric door and mounting tube assy. for 92" diag. through 106" diag. screens
1
$315.00
22054
Fabric door and mounting tube assy. for 109" diag. through 137" diag. screens
1
$410.00
17
22048
Stage right door assy. for 92" diag. through 106" diag. screens
1
$315.00
22047
Stage right door assy. for 109" diag. through 137" diag. screens
1
$351.00
18
20612KIT
Motor assy., 120v for 3.25" roller
1
$390.00
19
22084
Motor end bracket, dual
1
$50.00
20
22073
Cable assy., 60" data motor extension for 92" diag. through 106" diag. screens
1
$87.70
22071
Cable assy., 72" data motor extension for 106" diag. through 137" diag. screens
1
$93.50
21
22072
Cable assy., 60" power motor extension for 92" diag. through 106" diag. screens
1
$41.00
22070
Cable assy., 72" power motor extension for 106" diag. through 137" diag. screens
1
$46.70
22
22087
Motor end bracket for 2.25" roller
1
$22.25
23
32786
Motor and 2.25" roller assy., 120v
1
$730.00
24
94653
Cable clamp for wire cable
4
$13.65
25
22068
Stage Right Pulley
1
$117.00
26
22121
Steel Collar
2
$75.90
27
22067
Stage Left Pulley
1
$117.00
28
22088
Pin end bracket for 2.25" roller
1
$14.00
29
22082
Internal case mounting bracket
8
$5.85
30
22086
Pulley Mounting Bracket
4
$11.70
31
22101
Vented socket head cap screw, 3/8-16x1.50
2
$137.00
