58 Advantage (over 14’ W with Closure Door)
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
21635 Fabric and roller assy., Matte White 159" x 212" - 265" diag. 1 $3,377.00
21636 Fabric and roller assy., Matte White 177" x 236" - 295" diag. 1 $4,703.00
21632 Fabric and roller assy., Matte White 213" x 284" - 355" diag. 1 $7,597.00
Square Format
21622 Fabric and roller assy., Matte White 10' 6" x 14' 1 $2,266.00
21623 Fabric and roller assy., Matte White 14' x 14' 1 $2,716.00
21624 Fabric and roller assy., Matte White 12' x 16' 1 $2,656.00
21625 Fabric and roller assy., Matte White 16' x 16' 1 $3,275.00
21626 Fabric and roller assy., Matte White 13' 6" x 18' 1 $3,377.00
21627 Fabric and roller assy., Matte White 18' x 18' 1 $4,475.00
21628 Fabric and roller assy., Matte White 15' x 20' 1 $4,703.00
21629 Fabric and roller assy., Matte White 20' x 20' 1 $6,007.00
21630 Fabric and roller assy., Matte White 16' 6" x 22' 1 $5,451.00
21631 Fabric and roller assy., Matte White 22' x 22' 1 $6,637.00
5 Motor and roller assemblies include #21
38574
Motor and 1.563 roller assy., 120v 84" for 10'6 x 14', 14' x 14', 12' x 16', 16' x 16', 13'6" x 18', 18' x 18', 210" diag., 240"
diag., 265" diag., 216" diag., 243" diag., 208" diag. and 222" diag. screens
1 $570.00
38575 Motor and 1.563 roller assy., 120v 96" for 15' x 20', 20' x 20', 295" diag. and 271" diag. screens 1 $631.00
38579 Motor and 1.563 roller assy., 120v 108" for 16'6" x 22', 22' x 22' and 18' x 24' screens 1 $687.00
38574E
Motor and 1.563 roller assy., 240v 84" for 10'6 x 14', 14' x 14', 12' x 16', 16' x 16', 13'6" x 18', 18' x 18', 210" diag.,
240" diag., 265" diag., 216" diag., 243" diag., 208" diag. and 222" diag. screens
1 $570.00
38575E Motor and 1.563 roller assy., 240v 96" for 15' x 20', 20' x 20', 295" diag. and 271" diag. screens 1 $631.00
38579E Motor and 1.563 roller assy., 240v 108" for 16'6" x 22', 22' x 22' and 18' x 24' screens 1 $687.00
6 81662 Roller assy., 5.75" diam. for 14' and 210" diag. screens 1 $581.00
70756 Roller assy., 5.75" diam. for 208" diag. screens 1 $604.00
81663 Roller assy., 5.75" diam. for 16', 240" diag., 216" diag. and 222" diag. screens 1 $625.00
81664 Roller assy., 5.75" diam. for 18', 265" diag. and 243" diag. screens 1 $669.00
89110 Roller assy., 7" diam. for 20', 295" diag. and 271" diag. screens 1 $889.00
89111 Roller assy., 7" diam. for 22' screens 1 $944.00
89112 Roller assy., 7" diam. for 24' screens 1 $1,011.00
7 35905 Bolt for roller brackets 8 $1.75
35903 Nut for roller brackets 8 $1.17
95073 Washer for roller brackets 8 $0.37
8 35917 Bracket assy., pin end 1 $25.40
9 83017 Flanged bearing 1 $50.00
10 44731 Bolt to attach bearing to the bracket assy. 2 $0.23
44733 Washer for roller bracket assy. 2 $0.09
11 21463 Access/fabric doors and motor assy., 182 3/4" for 14' screens 1 $1,700.00
21464 Access/fabric doors and motor assy., 194 3/4" for 15' screens 1 $1,700.00
21465 Access/fabric doors and motor assy., 206 3/4" for 16' screens 1 $1,700.00
21466 Access/fabric doors and motor assy., 230 3/4" for 18' screens 1 $1,700.00
21467 Access/fabric doors and motor assy., 254 3/4" for 20' screens 1 $1,900.00
21468 Access/fabric doors and motor assy., 278 3/4" for 22' screens 1 $1,900.00
21469 Access/fabric doors and motor assy., 302 3/4" for 24' screens 1 $1,900.00
12 87056 Screw for ironing board 10-18 $0.20
37487 Nut for ironing board 10-18 $0.59
35891 Bracket for ironing board 5-9 $3.30
