194 Model C with CSR E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
14 45118 Plastic anchor for spring assy. for 3" roller 1 $2.65
15 58353 Spring assy. for 1 3/4" roller for 60" thru 72" screens (not shown) (prior to 1-17-12) 1 $28.10
80765 Roller plug for 1 3/4" roller (not shown) 1 $2.30
57706 Spring assy. for 3" roller (includes #13 and 14) 1 $101.00
16 Screen surface
HDTV (16:9) Format
84050 Fabric, Matte White 45" x 80" - 92" diag. (Prior to 2-8-19) 1 $213.00
92813 Fabric, High Contrast Matte White 45" x 80" - 92" diag. (Prior to 2-8-19) 1 $230.00
12184 Fabric, Matte White 45" x 80" - 92" diag. (2-8-19 and later) 1 $213.00
12185 Fabric, High Contrast Matte White 45" x 80" - 92" diag. (2-8-19 and later) 1 $230.00
78951 Fabric, Matte White 52" x 92" - 106" diag. (Prior to 2-8-19) 1 $294.00
92814 Fabric, High Contrast Matte White 52" x 92" - 106" diag. (Prior to 2-8-19) 1 $322.00
12187 Fabric, Matte White 52" x 92" - 106" diag. (2-8-19 and later) 1 $294.00
12188 Fabric, High Contrast Matte White 52" x 92" - 106" diag. (2-8-19 and later) 1 $322.00
94379 Fabric, Matte White 54" x 96" - 110" diag. 1 $322.00
94380 Fabric, High Contrast Matte White 54" x 96" - 110" diag. 1 $353.00
78954 Fabric, Matte White 58" x 104" - 119" diag. 1 $343.00
92815 Fabric, High Contrast Matte White 58" x 104" - 119" diag. 1 $377.00
78957 Fabric, Matte White 65" x 116" - 133" diag. 1 $395.00
92816 Fabric, High Contrast Matte White 65" x 116" - 133" diag. 1 $435.00
78960 Fabric, Matte White 78" x 139" - 159" diag. 1 $641.00
92817 Fabric, High Contrast Matte White 78" x 139" - 159" diag. 1 $663.00
Wide (16:10) Format
34841 Fabric, Matte White 50" x 80" - 94" diag. (Prior to 2-8-19) 1 $213.00
34842 Fabric, High Contrast Matte White 50" x 80" - 94" diag. (Prior to 2-8-19) 1 $230.00
12202 Fabric, Matte White 50" x 80" - 94" diag. (2-8-19 and later) 1 $213.00
12203 Fabric, High Contrast Matte White 50" x 80" - 94" diag. (2-8-19 and later) 1 $230.00
70457 Fabric, Matte White 57.5" x 92" - 109" diag. (Prior to 2-8-19) 1 $294.00
70458 Fabric, High Contrast Matte White 57.5" x 92" - 109" diag. (Prior to 2-8-19) 1 $322.00
12205 Fabric, Matte White 57.5" x 92" - 109" diag. (2-8-19 and later) 1 $294.00
12206 Fabric, High Contrast Matte White 57.5" x 92" - 109" diag. (2-8-19 and later) 1 $322.00
34845 Fabric, Matte White 60" x 96" - 113" diag. 1 $322.00
34846 Fabric, High Contrast Matte White 60" x 96" - 113" diag. 1 $353.00
21653 Fabric, Matte White 65" x 104" - 123" diag. 1 $343.00
21654 Fabric, High Contrast Matte White 65" x 104" - 123" diag. 1 $377.00
34849 Fabric, Matte White 69" x 110" - 130" diag. 1 $395.00
34850 Fabric, High Contrast Matte White 69" x 110" - 130" diag. 1 $435.00
70461 Fabric, Matte White 72.5" x 116" - 137" diag. 1 $395.00
70462 Fabric, High Contrast Matte White 72.5" x 116" - 137" diag. 1 $435.00
34853 Fabric, Matte White 87" x 139" - 164" diag. 1 $641.00
34854 Fabric, High Contrast Matte White 87" x 139" - 164" diag. 1 $663.00
Video (4:3) Format
93475 Fabric, Matte White 43" x 57" - 72" diag. 1 $116.00
93476 Fabric, High Contrast Matte White 43" x 57" - 72" diag. 1 $127.00
93480 Fabric, Matte White 50" x 67" - 84" diag. 1 $142.00
93481 Fabric, High Contrast Matte White 50" x 67" - 84" diag. 1 $155.00
