165 Da-Snap E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
Wide (16:10) Format
34993 Frame assy. for 94" diag. 16:10 screens 1 $823.00
70525 Frame assy. for 109" diag. 16:10 screens 1 $1,045.00
35023 Frame assy. for 113" diag. 16:10 screens 1 $1,097.00
21927 Frame assy, for 123" diag. 16:10 screens 1 $1,259.00
34996 Frame assy. for 130" diag. 16:10 screens 1 $1,364.00
70526 Frame assy. for 137" diag. 16:10 screens 1 $1,467.00
34998 Frame assy. for 164" diag. 16:10 screens 1 $1,580.00
70527 Frame assy. for 189" diag. 16:10 screens 1 $1,756.00
70528 Frame assy. for 208" diag. 16:10 screens 1 $1,821.00
70529 Frame assy. for 226" diag. 16:10 screens 1 $1,857.00
2.35:1 Cinemascope Format
97795 Frame assy. for 96" diag. CS screens 1 $765.00
97796 Frame assy. for 103" diag. CS screens 1 $1,086.00
97797 Frame assy. for 115" diag. CS screens 1 $1,259.00
97798 Frame assy. for 125" diag. CS screens 1 $1,452.00
97799 Frame assy. for 133" diag. CS screens 1 $1,498.00
97800 Frame assy. for 138" diag. CS screens 1 $1,545.00
39215 Frame assy. for 148" diag. CS screens 1 $1,604.00
39216 Frame assy. for 166" diag. CS screens 1 $1,715.00
39217 Frame assy. for 199" diag. CS screens 1 $1,821.00
39218 Frame assy. for 208" diag. CS screens 1 $1,857.00
3b Pro Trim Frame Assembly
HDTV (16:9) Format
93267V Pro Trim frame assy. for 77" diag. screens 1 $943.00
96948V Pro Trim frame assy. for 82" diag. screens 1 $967.00
85952V Pro Trim frame assy. for 92" diag. screens 1 $1,016.00
93702V Pro Trim frame assy. for 100" HD diag. screens 1 $1,130.00
85953V Pro Trim frame assy. for 106" diag. screens 1 $1,247.00
94701V Pro Trim frame assy. for 110" diag. screens 1 $1,286.00
85954V Pro Trim frame assy. for 119" diag. screens 1 $1,458.00
85955V Pro Trim frame assy. for 133" diag. screens 1 $1,667.00
85956V Pro Trim frame assy. for 159" diag. screens 1 $1,767.00
94088V Pro Trim frame assy. for 193" diag. screens 1 $2,103.00
94089V Pro Trim frame assy. for 220" diag. screens 1 $2,369.00
Wide (16:10) Format
34993V Pro Trim frame assy. for 94" diag. 16:10 screens 1 $1,024.00
70525V Pro Trim frame assy. for 109" diag. 16:10 screens 1 $1,240.00
35023V Pro-Trim frame assy. for 113" diag. 16:10 screens 1 $1,298.00
21927V Pro-Trim frame assy, for 123" diag. 16:10 screens 1 $1,453.00
34996V Pro-Trim frame assy. for 130" diag. 16:10 screens 1 $1,563.00
70526V Pro Trim frame assy. for 137" diag. 16:10 screens 1 $1,661.00
34998V Pro-Trim frame assy. for 164" diag. 16:10 screens 1 $1,783.00
70527V Pro Trim frame assy. for 189" diag. 16:10 screens 1 $1,949.00
70528V Pro Trim frame assy. for 208" diag. 16:10 screens 1 $2,015.00
70529V Pro Trim frame assy. for 226" diag. 16:10 screens 1 $2,053.00
