6 E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
DL–0736 (Rev. 2) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
12744 Fabric Assembly, Parallax Stratos 1.0 87" x 139" - 164" Diagonal 1 $2,517.00
29709 Fabric Assembly, HD Progressive 0.6 87" x 139" - 164" Diagonal 1 $2,397.00
29675 Fabric Assembly, HD Progressive 0.9 87" x 139" - 164" Diagonal 1 $2,397.00
29710 Fabric Assembly, HD Progressive 1.1 87" x 139" - 164" Diagonal 1 $2,397.00
12413 Fabric Assembly, HD Progressive 1.1 Contrast 87" x 139" - 164" Diagonal 1 $2,397.00
29711 Fabric Assembly, HD Progressive 1.3 87" x 139" - 164" Diagonal 1 $2,397.00
29712 Fabric Assembly, HD Progressive ReView 0.9 87" x 139" - 164" Diagonal 1 $2,276.00
12745 Fabric Assembly, Parallax Stratos 1.0 100" x 160" - 189" Diagonal 1 $2,756.00
29713 Fabric Assembly, HD Progressive 0.6 100" x 160" - 189" Diagonal 1 $2,625.00
29714 Fabric Assembly, HD Progressive 0.9 100" x 160" - 189" Diagonal 1 $2,625.00
29651 Fabric Assembly, HD Progressive 1.1 100" x 160" - 189" Diagonal 1 $2,625.00
12414 Fabric Assembly, HD Progressive 1.1 Contrast 100" x 160" - 189" Diagonal 1 $2,625.00
29715 Fabric Assembly, HD Progressive 1.3 100" x 160" - 189" Diagonal 1 $2,625.00
29716 Fabric Assembly, HD Progressive ReView 0.9 100" x 160" - 189" Diagonal 1 $2,493.00
12746 Fabric Assembly, Parallax Stratos 1.0 110" x 176" - 208" Diagonal 1 $2,875.00
29717 Fabric Assembly, HD Progressive 0.6 110" x 176" - 208" Diagonal 1 $2,738.00
29718 Fabric Assembly, HD Progressive 0.9 110" x 176" - 208" Diagonal 1 $2,738.00
29719 Fabric Assembly, HD Progressive 1.1 110" x 176" - 208" Diagonal 1 $2,738.00
12415 Fabric Assembly, HD Progressive 1.1 Contrast 110" x 176" - 208" Diagonal 1 $2,738.00
29720 Fabric Assembly, HD Progressive 1.3 110" x 176" - 208" Diagonal 1 $2,738.00
29721 Fabric Assembly, HD Progressive ReView 0.9 110" x 176" - 208" Diagonal 1 $2,602.00
12747 Fabric Assembly, Parallax Stratos 1.0 120" x 192" - 226" Diagonal 1 $3,115.00
29612 Fabric Assembly, HD Progressive 0.6 120" x 192" - 226" Diagonal 1 $2,967.00
29656 Fabric Assembly, HD Progressive 0.9 120" x 192" - 226" Diagonal 1 $2,967.00
29722 Fabric Assembly, HD Progressive 1.1 120" x 192" - 226" Diagonal 1 $2,967.00
12416 Fabric Assembly, HD Progressive 1.1 Contrast 120" x 192" - 226" Diagonal 1 $2,967.00
29723 Fabric Assembly, HD Progressive 1.3 120" x 192" - 226" Diagonal 1 $2,967.00
29724 Fabric Assembly, HD Progressive ReView 0.9 120" x 192" - 226" Diagonal 1 $2,818.00
22 10685 Tab for screen surface Varies $0.37
23 92030 Cap for slat assembly 2 $9.15
24 44839 Screw to attach cap to slat assembly 4 $0.27
25 29350 Flipper for pin end side 1 $217.00
26 29243 Universal interface control 120V (not shown) 1 $1,201.00
99472 Radio frequency transmitter for 120V (not shown) 1 $201.00
28359 Wall switch, single channel white 120V (not shown) 1 $368.00
71912 Dry Contact Transmitter 120V (not shown) 1 $255.00
10644 Radio frequency transmitter for 220V (not shown) 1 $258.00
29469 Dry Contact Transmitter 220V (not shown) 1 $255.00
29470 Wall switch, single channel white 220V (not shown) 1 $256.00
29471 Radio frequency repeater 220V (not shown) 1 $257.00
