Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) User Manual
Page 106
106
DL–0660 (Rev. 3) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
27
20611KIT
Motor assy., 120v for standard and SCB-100 screens with 3" rollers
1
$390.00
20611SKIT
Motor assy., 120v Silent for standard and SCB-100 screens with 3" rollers
1
$487.00
22290KIT
Motor assy., 120v for SCB-200 screens with 3" rollers
1
$390.00
22290SKIT
Motor assy., 120v Silent for SCB-200 screens with 3" rollers
1
$487.00
38891KIT
Motor assy., 120v for LVC and VPI screens with 3" rollers
1
$487.00
38891LSKIT Motor assy., 120v Silent for LVC and VPI screens with 3" rollers up to and including 10' x 10'
1
$585.00
20612KIT
Motor assy., 120v for standard and SCB-100 screens with 3.25" rollers up to and including 10' x 10'
1
$390.00
20612SKIT
Motor assy., 120v Silent for standard and SCB-100 screens with 3.25" rollers up to and including 10' x 10'
1
$487.00
22291KIT
Motor assy., 120v for SCB-200 screens with 3.25" rollers up to and including 10' x 10'
1
$390.00
22291SKIT
Motor assy., 120v Silent for SCB-200 screens with 3.25" rollers up to and including 10' x 10'
1
$487.00
38890KIT
Motor assy., 120v for LVC and VPI screens with 3.25" rollers
1
$487.00
38890LSKIT Motor assy., 120v Silent for LVC and VPI screens with 3.25" rollers up to and including 10' x 10'
1
$585.00
37989KIT
Motor assy., 120v for standard and SCB-100 screens over 10' wide with 3.25" rollers
1
$390.00
37990KIT
Motor assy., 120v for SCB-200 screens over 10' wide with 3.25" rollers
1
$390.00
20613KIT
Motor assy., 240v for standard, SCB-100/200 and VPI screens with 3" rollers up to and including 10' x 10'
1
$390.00
20613SKIT
Motor assy., 240v Silent for standard, SCB-100/200 and VPI screens with 3" rollers up to and including 10'
x 10'
1
$487.00
30833KIT
Motor assy., 240v for LVC screens with 3" rollers before 4/12/2018
1
$800.00
12146KIT
Motor assy., 240v for LVC screens with 3" rollers 4/12/2018 and after
1
$487.00
30833LSKIT Motor assy., 240v Silent for LVC screens with 3" rollers before 6/11/2018
1
$585.00
12278KIT
Motor assy., 240v Silent for LVC screens with 3" rollers 6/11/2018 and after
1
$585.00
20614KIT
Motor assy., 240v for standard, SCB-100/200 and VPI screens with 3.25" rollers up to and including 10' x 10'
1
$390.00
20614SKIT
Motor assy., 240v Silent for standard, SCB-100/200 and VPI screens with 3.25" rollers up to and including
10' x 10'
1
$487.00
32645KIT
Motor assy., 240v for LVC screens with 3.25" rollers before 4/12/2018
1
$800.00
32703RPL
Motor assy., 240v for 12' x 12' LVC screens with 3.25" rollers before 4/12/2018
1
$1,000.00
12147KIT
Motor assy., 240v for all LVC screens with 3.25" rollers 4/12/2018 and after
1
$487.00
32645LSKIT Motor assy., 240v Silent for LVC screens with 3.25" rollers up to and including 10' x 10' before 6/11/2018
1
$585.00
12279KIT
Motor assy., 240v Silent for LVC screens with 3.25" rollers up to and including 10' x 10' 6/11/2018 and after
1
$585.00
32693KIT
Motor assy., 240v for standard and SCB-100/200 screens over 10' wide with 3.25" rollers
1
$390.00
94785
Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown)
1
$60.00
28
97290
Hair cotter pin, 5/16" - 3/8" x 1 5/8"
1
$0.47
29
38885
LVC / Smart motor hardware kit (not shown). For 120V screens with built-in LVC. Includes wall switch.
1
$298.00
99607
LVC / ILT motor hardware kit (not shown). For 220V screens with built-in LVC. Includes wall switch.
1
$120.00
38885B
LVC / Smart motor hardware kit for case only (not shown). For 120V screens with built-in LVC. Includes
wall switch.
1
$94.40
99607B
LVC / ILT motor hardware kit for case only (not shown). For 220V screens with built-in LVC. Includes wall
switch.
1
$94.40
80575
Wall switch, 120v white (not shown)
1
$77.00
40961
Wall switch, 120v ivory (not shown)
1
$77.00
11147
Wall switch, 240v white double push putton (not shown)
1
$77.00
38463E
Wall switch, 240v white rocker (not shown)
1
$77.00
