Tensioned Conference Electrol
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
1
44839
Screw for slat cap assy.
4
$0.27
2
92030
Slat cap assy. (includes #1)
2
$9.15
3
10685
Tab
14-22
$0.37
4
75658
Line, chalk and mason black (per foot). Figure one side at approximately height of fabric + 2' + any extra
needed.
Per size
$0.23
5
Fabric and roller assemblies include #2, 3 and 4
HDTV (16:9) Format
22313
Fabric and roller assy., HD Progressive 0.9 45" x 80" - 92" diag.
1
$1,555.00
22314
Fabric and roller assy., HD Progressive 1.1 45" x 80" - 92" diag.
1
$1,555.00
90401
Fabric and roller assy., HD Progressive 1.1 Contrast 45" x 80" - 92" diag.
1
$1,555.00
29177
Fabric and roller assy., HD Progressive 1.3 45" x 80" - 92" diag.
1
$1,555.00
84695
Fabric and roller assy., Da-Mat 45" x 80" - 92" diag.
1
$1,291.00
22316
Fabric and roller assy., HD Progressive 0.9 52" x 92" - 106" diag.
1
$1,724.00
22317
Fabric and roller assy., HD Progressive 1.1 52" x 92" - 106" diag.
1
$1,724.00
90402
Fabric and roller assy., HD Progressive 1.1 Contrast 52" x 92" - 106" diag.
1
$1,724.00
29178
Fabric and roller assy., HD Progressive 1.3 52" x 92" - 106" diag.
1
$1,724.00
80314
Fabric and roller assy., Da-Mat 52" x 92" - 106" diag.
1
$1,431.00
22319
Fabric and roller assy., HD Progressive 0.9 54" x 96" - 110" diag.
1
$1,893.00
22320
Fabric and roller assy., HD Progressive 1.1 54" x 96" - 110" diag.
1
$1,893.00
95092
Fabric and roller assy., HD Progressive 1.1 Contrast 54" x 96" - 110" diag.
1
$1,893.00
29179
Fabric and roller assy., HD Progressive 1.3 54" x 96" - 110" diag.
1
$1,893.00
95088
Fabric and roller assy., Da-Mat 54" x 96" - 110" diag.
1
$1,571.00
22322
Fabric and roller assy., HD Progressive 0.9 58" x 104" - 119" diag.
1
$2,111.00
22323
Fabric and roller assy., HD Progressive 1.1 58" x 104" - 119" diag.
1
$2,111.00
90403
Fabric and roller assy., HD Progressive 1.1 Contrast 58" x 104" - 119" diag.
1
$2,111.00
29180
Fabric and roller assy., HD Progressive 1.3 58" x 104" - 119" diag.
1
$2,111.00
80317
Fabric and roller assy., Da-Mat 58" x 104" - 119" diag.
1
$1,752.00
22325
Fabric and roller assy., HD Progressive 0.9 65" x 116" - 133" diag.
1
$2,393.00
22326
Fabric and roller assy., HD Progressive 1.1 65" x 116" - 133" diag.
1
$2,393.00
90404
Fabric and roller assy., HD Progressive 1.1 Contrast 65" x 116" - 133" diag.
1
$2,393.00
29181
Fabric and roller assy., HD Progressive 1.3 65" x 116" - 133" diag.
1
$2,393.00
80320
Fabric and roller assy., Da-Mat 65" x 116" - 133" diag.
1
$1,986.00
Wide (16:10) Format
22333
Fabric and roller assy., HD Progressive 0.9 50" x 80" - 94" diag.
1
$1,555.00
22334
Fabric and roller assy., HD Progressive 1.1 50" x 80" - 94" diag.
1
$1,555.00
34877
Fabric and roller assy., HD Progressive 1.1 Contrast 50" x 80" - 94" diag.
1
$1,555.00
29188
Fabric and roller assy., HD Progressive 1.3 50" x 80" - 94" diag.
1
$1,555.00
34873
Fabric and roller assy., Da-Mat 50" x 80" - 94" diag.
1
$1,291.00
22335
Fabric and roller assy., HD Progressive 0.9 57 1/2" x 92" - 109" diag.
1
$1,724.00
22336
Fabric and roller assy., HD Progressive 1.1 57 1/2" x 92" - 109" diag.
1
$1,724.00
21110
Fabric and roller assy., HD Progressive 1.1 Contrast 57 1/2" x 92" - 109" diag.
1
$1,724.00
29189
Fabric and roller assy., HD Progressive 1.3 57 1/2" x 92" - 109" diag.
1
$1,724.00
21106
Fabric and roller assy., Da-Mat 57 1/2" x 92" - 109" diag.
1
$1,431.00
22337
Fabric and roller assy., HD Progressive 0.9 60" x 96" - 113" diag.
1
$1,893.00
22338
Fabric and roller assy., HD Progressive 1.1 60" x 96" - 113" diag.
1
$1,893.00
34887
Fabric and roller assy., HD Progressive 1.1 Contrast 60" x 96" - 113" diag.
1
$1,893.00
29190
Fabric and roller assy., HD Progressive 1.3 60" x 96" - 113" diag.
1
$1,893.00
34883
Fabric and roller assy., Da-Mat 60" x 96" - 113" diag.
1
$1,571.00
