Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
30 44785 Screw to attach access door bracket assy. to the door 2 $0.16
31 Access door assemblies include #9 and 10
HDTV (16:9) Format
84107 Access door assy. for 92" diag. screens 1 $105.00
79372 Access door assy. for 106" diag. screens 1 $107.00
94821 Access door assy. for 110" diag. screens 1 $109.00
79373 Access door assy. for 119" diag. screens 1 $109.00
79374 Access door assy. for 133" diag. screens 1 $116.00
79375 Access door assy. for 159" diag. screens 1 $117.00
35838 Access door assy. for 184" diag. screens 1 $119.00
Wide (16:10) Format
34968 Access door assy. for 94" diag. screens 1 $105.00
71159 Access door assy. for 109" diag. screens 1 $107.00
34969 Access door assy. for 113" diag. screens 1 $109.00
20670 Access door assy. for 123" diag. screens 1 $109.00
34970 Access door assy. for 130" diag. screens 1 $116.00
97845 Access door assy. for 137" diag. screens 1 $116.00
34971 Access door assy. for 164" diag. screens 1 $117.00
70945 Access door assy. for 189" diag. screens 1 $119.00
Video (4:3) Format
79367 Access door assy. for 72" diag. screens 1 $87.90
79368 Access door assy. for 84" diag. screens 1 $90.00
79369 Access door assy. for 100" diag. screens 1 $105.00
79370 Access door assy. for 120" diag. screens 1 $107.00
79371 Access door assy. for 150" diag. screens 1 $116.00
82718 Access door assy. for 180" diag. screens 1 $117.00
82719 Access door assy. for 200" diag. screens 1 $119.00
32 35851 Timer relay and wire assy., 120v for screens with SCB100/200 1 $249.00
35902 Relay and wire assy., 120v for screens with LVC 1 $249.00
35852 Timer relay and wire assy., 240v for screens with SCB100/200 1 $249.00
37999 Relay and wire assy., 240v for screens with LVC 1 $249.00
33 94501 Junction box (excluded when you have an LVC) 1 $11.25
34 94503WHITE Junction box cover (excluded when you have an LVC) 1 $2.65
36 95443 Black bushing (excluded when you have an LVC) 1 $0.18
37 95016 Microswitch assy., 120v 1 $20.40
32580 Microswitch assy., 240v 1 $20.40
38 90869 Hangers and hardware for under 8' screens (not shown) 1 $20.40
90870 Hangers and hardware for 8' and over screens (not shown) 1 $24.15
40975 3-Button switch-LVC, white (not shown) 1 $101.00
