Da-Lite 37989KIT Motor Drive Wheel Kit (120 VAC) User Manual
Page 13
13
Tensioned Advantage (with Closure Door)
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
21
20612KIT
Motor assy., 120v for standard screens with 3.25" rollers up to and including 10' x 10'
1
$390.00
37989KIT
Motor assy., 120v for standard screens over 10' wide with 3.25" rollers
1
$390.00
33154KIT
Motor assy., 120v for SCB100/200 with 3.25" rollers
1
$390.00
20614KIT
Motor assy., 240v for standard screens with 3.25" rollers up to and including 10' x 10'
1
$390.00
32692KIT
Motor assy., 240v for standard screens over 10' wide with 3.25" rollers
1
$390.00
32641KIT
Motor assy., 240v for SCB100/200 with 3.25" rollers
1
$390.00
22
38003
Motor assy., 120v for 1.59" roller (included in #19) (not shown)
1
$243.00
32732
Motor assy., 240v for 1.59" roller (included in #19) (not shown)
1
$243.00
94785TABS Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown)
1
$40.00
23
34201WHITE Motor end bracket for 3.25" roller, white
1
$20.40
34189WHITE Motor end bracket for 1.59" roller, white (not shown)
1
$20.40
24
97290
Hair cotter pin, 5/16" - 3/8" x 1 5/8"
1
$0.47
25
94693
Motor end bracket, cover white
1
$9.70
34203WHITE Motor end bracket, cover white for SCB100/200 screens
1
$9.70
26
94719
Access door bracket
2
$6.10
27
72537
Screw for access door bracket(pre 8/16)
2
$0.32
10908
Screw for access door bracket(8/16 and later)
2
$0.32
28
70034
Motor end cap assy., 120v for Standard screens (includes #26, 27 and 37) effective 1-03-11
1
$399.00
70036
Motor end cap assy., 120v for VPI screens (includes #37) effective 1-03-11
1
$499.00
70035
Motor end cap assy., 240v for Standard screens (includes #26, 27 and 37) effective 1-03-11
1
$399.00
70037
Motor end cap assy., 240v for VPI screens (includes # 37) effective 1-03-11
1
$499.00
29
Fabric door assemblies include #9 and 10
HDTV (16:9) Format
84106
Fabric door assy. for 92" diag. screens
1
$99.20
79355
Fabric door assy. for 106" diag. screens
1
$109.00
94820
Fabric door assy. for 110" diag. screens
1
$111.00
79356
Fabric door assy. for 119" diag. screens
1
$116.00
79357
Fabric door assy. for 133" diag. screens
1
$119.00
79358
Fabric door assy. for 159" diag. screens
1
$124.00
35837
Fabric door assy. for 184" diag. screens
1
$132.00
Wide (16:10) Format
34964
Fabric door assy. for 94" diag. screens
1
$99.20
71158
Fabric door assy. for 109" diag. screens
1
$107.00
34965
Fabric door assy. for 113" diag. screens
1
$111.00
20669
Fabric door assy. for 123" diag. screens
1
$116.00
34966
Fabric door assy. for 130" diag. screens
1
$117.00
97844
Fabric door assy. for 137" diag. screens
1
$119.00
34967
Fabric door assy. for 164" diag. screens
1
$124.00
Video (4:3) Format
79350
Fabric door assy. for 72" diag. screens
1
$87.90
79351
Fabric door assy. for 84" diag. screens
1
$92.10
79352
Fabric door assy. for 100" diag. screens
1
$99.20
79353
Fabric door assy. for 120" diag. screens
1
$109.00
79354
Fabric door assy. for 150" diag. screens
1
$119.00
82711
Fabric door assy. for 180" diag. screens
1
$124.00
82712
Fabric door assy. for 200" diag. screens
1
$132.00
70944
Fabric door assy. for 189" diag. screens
1
$132.00
