Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
Video (4:3) Format
71105 Fabric and roller assy., Matte White 120" x 160" - 200" diag. 1 $1,984.00
71106 Fabric and roller assy., Matte White 123" x 164" - 210" diag. 1 $2,233.00
71107 Fabric and roller assy., Matte White 141" x 188" - 240" diag. 1 $2,612.00
71108 Fabric and roller assy., Matte White 159" x 212" - 265" diag. 1 $3,377.00
71109 Fabric and roller assy., Matte White 177" x 236" - 295" diag. 1 $4,703.00
71110 Fabric and roller assy., Matte White 195" x 260" - 325" diag. 1 $5,420.00
71111 Fabric and roller assy., Matte White 213" x 284" - 355" diag. 1 $6,000.00
Square Format
71090 Fabric and roller assy., Matte White 9' x 12' 1 $1,105.00
71091 Fabric and roller assy., Matte White 12' x 12' 1 $2,112.00
71092 Fabric and roller assy., Matte White 10' 6" x 14' 1 $2,266.00
71093 Fabric and roller assy., Matte White 14' x 14' 1 $2,716.00
71094 Fabric and roller assy., Matte White 12' x 16' 1 $2,656.00
71095 Fabric and roller assy., Matte White 16' x 16' 1 $3,275.00
71096 Fabric and roller assy., Matte White 13' 6" x 18' 1 $3,377.00
71097 Fabric and roller assy., Matte White 18' x 18' 1 $4,475.00
71098 Fabric and roller assy., Matte White 15' x 20' 1 $4,703.00
71099 Fabric and roller assy., Matte White 20' x 20' 1 $6,007.00
71100 Fabric and roller assy., Matte White 11' x 22' 1 $5,300.00
71101 Fabric and roller assy., Matte White 16' 6" x 22' 1 $5,451.00
71102 Fabric and roller assy., Matte White 22' x 22' 1 $6,637.00
71103 Fabric and roller assy., Matte White 12' x 24' 1 $6,000.00
71104 Fabric and roller assy., Matte White 18' x 24' 1 $7,597.00
5 83702 Screw for ironing board 5-9 $0.16
6 44735 Lock washer for ironing board 5-9 $0.45
7 97724 Ironing board bracket for 14' -24' screens 5-9 $3.30
8 50877 Nut for ironing board 5-9 $0.90
9 83501 Screw for roller bracket 8 $0.60
10 83699 Ironing board for 14, 200" diag., 210" diag. and 188" diag. screens 1 $101.00
83718 Ironing board for 16', 240" diag. and 216" diag. screens 1 $107.00
83719 Ironing board for 18', 265" diag. and 243" diag. screens 1 $117.00
83720 Ironing board for 20', 295" diag. and 271" diag. screens 1 $119.00
83721 Ironing board for 22', 325" diag. and 298" diag. screens 1 $120.00
83382 Ironing board for 24', 355" diag. and 326" diag. screens 1 $124.00
11 44777 Screw for ironing board bracket 5-9 $0.16
12 83010 Roller bracket, pin end for 12'-18' screens 1 $16.55
89038 Roller bracket, pin end for 20'-24' screens 1 $17.55
83017 Bearing, flange 1 $50.00
13 81796 Wood box assy. for 12' and 159" diag. screens 1 $1,389.00
33026 Wood box assy. for 200" diag. screens 1 $1,475.00
81667 Wood box assy. for 14', 210" diag. and 188" diag. screens 1 $1,656.00
81668 Wood box assy. for 16', 240" diag. and 216" diag. screens 1 $1,723.00
81669 Wood box assy. for 18', 265" diag. and 243" diag. screens 1 $1,785.00
89115 Wood box assy. for 20', 295" diag. and 271" diag. screens 1 $2,001.00
89116 Wood box assy. for 22', 325" diag. and 298" diag. screens 1 $2,144.00
89117 Wood box assy. for 24', 355" diag. and 326" diag. screens 1 $2,283.00
