Page 32
32
Tensioned Advantage® (over 14’ W with Closure Door)
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
12769
Fabric and roller assy., Parallax Stratos 1.0 120" x 192" - 226" diag.
1
$5,116.00
22359
Fabric and roller assy., HD Progressive 0.9 120" x 192" - 226" diag.
1
$4,872.00
22360
Fabric and roller assy., HD Progressive 1.1 120" x 192" - 226" diag.
1
$4,872.00
21547
Fabric and roller assy., HD Progressive 1.1 Contrast 120" x 192" - 226" diag.
1
$4,872.00
29201
Fabric and roller assy., HD Progressive 1.3 120" x 192" - 226" diag.
1
$4,872.00
21549
Fabric and roller assy., HD Progressive ReView 0.9 120" x 192" - 226" diag.
1
$4,872.00
21543
Fabric and roller assy., Da-Mat 120" x 192" - 226" diag.
1
$4,015.00
21548
Fabric and roller assy., Da-Tex 120" x 192" - 226" diag.
1
$4,477.00
Video (4:3) Format
39334
Fabric and roller assy., Da-Mat 126" x 168" - 210" diag.
1
$3,594.00
39341
Fabric and roller assy., Da-Mat 132" x 176" - 220" diag.
1
$3,741.00
39348
Fabric and roller assy., Da-Mat 144" x 192" - 240" diag.
1
$4,092.00
36802
Fabric and roller assy., Da-Mat 162" x 216" - 270" diag.
1
$4,206.00
6
Motor and roller assemblies include #19
38574
Motor and 1.563 roller assy., 120v 84" for 10'6 x 14', 14' x 14', 12' x 16', 210" diag., 220" diag., 240" diag., 220" HD
diag., 208" diag. and 226" diag. screens
1
$570.00
38575
Motor and 1.563 roller assy., 120v 96" for 270" diag. and 247" diag. screens
1
$631.00
38579
Motor and 1.563 roller assy., 120v 108" for 275" diag. and 298" diag. screens
1
$687.00
38574E
Motor and 1.563 roller assy., 240v 84" for 10'6 x 14', 14' x 14', 12' x 16', 210" diag., 220" diag., 240" diag., 220" HD
diag., 208" diag. and 226" diag. screens
1
$570.00
38575E
Motor and 1.563 roller assy., 240v 96" for 270" diag. and 247" diag. screens
1
$631.00
38579E
Motor and 1.563 roller assy., 240v 108" for 275" diag. and 298" diag. screens
1
$687.00
7
35905
Bolt for roller brackets
8
$1.75
35903
Nut for roller brackets
8
$1.17
95073
Washer for roller brackets
8
$0.37
8
35917
Bracket assy., pin end
1
$25.40
9
83017
Flanged bearing
1
$50.00
10
44731
Bolt to attach bearing to the bracket assy.
2
$0.23
44733
Washer for roller bracket assy.
2
$0.09
11
Access/fabric doors and motor assemblies include #6
HDTV (16:9) Format
21554
Access/fabric doors and motor assy., 220" for 220" HD diag. screens
1
$1,700.00
21555
Access/fabric doors and motor assy., 246" for 247" diag. screens
1
$1,900.00
21556
Access/fabric doors and motor assy., 272" for 275" diag. screens
1
$1,900.00
21557
Access/fabric doors and motor assy., 293 1/2" for 298" diag. screens
1
$1,900.00
Wide (16:10) Format
21558
Access/fabric doors and motor assy., 204 3/4" for 208" diag. screens
1
$1,700.00
21559
Access/fabric doors and motor assy., 221 1/2" for 226" diag. screens
1
$1,700.00
Video (4:3) Format
21550
Access/fabric doors and motor assy., 198 1/2" for 210" diag. screens
1
$1,700.00
21552
Access/fabric doors and motor assy., 225" for 240" diag. screens
1
$1,700.00
21551
Access/fabric doors and motor assy., 207 1/2" for 220" diag. screens
1
$1,700.00
21553
Access/fabric doors and motor assy., 250 1/2" for 270" diag. screens
1
$1,900.00
12
35907
Screws to attach the end caps
8
$0.80
13
35885
Pin end cap assy.
1
$58.50
14
35888
Door bracket assy.
2
$7.80
15
80874
Nut to attach bracket assy.
4
$0.32
