27 Tensioned Advantage (with ViewShare)
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
21759 White door for 123" diag. SCB-100/200 screens 1 $111.00
34947 White door for 130" diag. SCB-100/200 screens 1 $116.00
70958 White door for 137" diag. SCB-100/200 screens 1 $117.00
12 79659 Screw for door 2 $0.16
13 84225 Door bracket 2 $3.20
14 10908 Screw for door bracket (8/16 and later) 2 $0.32
72537 Screw for door bracket (pre 8/16) 2 $0.32
15 50747 Screw for universal end cap 8 $0.16
16 96336WHITE Pin end cap, white 1 $22.65
17a White case for standard Screens. See 17b for SCB-100/200 screens.
HDTV (16:9) Format
84569 White case for 92" diag. standard and LVC screens 1 $623.00
84534 White case for 106" diag. standard and LVC screens 1 $684.00
94304 White case for 110" diag. standard and LVC screens 1 $705.00
84537 White case for 119" diag. standard and LVC screens 1 $730.00
84540 White case for 133" diag. standard and LVC screens 1 $815.00
Wide (16:10) Format
34936 White case for 94" diag. standard and LVC screens 1 $623.00
70770 White case for 109" diag. standard and LVC screens 1 $684.00
34938 White case for 113" diag. standard and LVC screens 1 $705.00
21752 White case for 123" diag. standard and LVC screens 1 $730.00
91730 White case for 130" diag. standard and LVC screens 1 $785.00
91719 White case for 137" diag. standard and LVC screens 1 $807.00
17b White case for SCB-100/200 screens.
HDTV (16:9) Format
91757 White case for 92" diag. SCB-100/200 screens 1 $633.00
91758 White case for 106" diag. SCB-100/200 screens 1 $692.00
95118 White case for 110" diag. SCB-100/200 screens 1 $717.00
91759 White case for 119" diag. SCB-100/200 screens 1 $763.00
91760 White case for 133" diag. SCB-100/200 screens 1 $827.00
Wide (16:10) Format
34937 White case for 94" diag. SCB-100/200 screens 1 $633.00
34933 White case for 109" diag. SCB-100/200 screens 1 $763.00
34939 White case for 113" diag. SCB-100/200 screens 1 $717.00
21758 White case for 123" diag. SCB-100/200 screens 1 $763.00
34940 White case for 130" diag. SCB-100/200 screens 1 $807.00
70957 White case for 137" diag. SCB-100/200 screens 1 $827.00
18 24603LS Motor end cap, white 120v for LVC screens 1 $59.30
24650LS Motor end cap, white 240v for LVC screens 1 $59.30
96334WHITE Motor end cap, white for SCB-100/200 screens 1 $22.65
34165WHITE Motor end cap, white with internal junction box (not shown) 1 $22.65
19 99584WASH Junction box 1 $11.25
94501 Junction box, internal (not shown) 1 $11.25
20 99585WASH Junction box cover 1 $6.00
94503WHITE Junction box cover, internal (not shown) 1 $2.65
21 84470 Connector assy., 120v for standard screens 1 $7.00
84482 Connector assy., 240v for standard screens 1 $7.00
