69 Tensioned Professional Electrol E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
1 44839 Screw for slat cap assy. 4 $0.27
2 98895 Slat cap assy. (includes #1) 2 $40.00
3 10685 Tab 24-44 $0.37
4 75658
Line, chalk and mason black (per foot). Figure one side at approximately height of fabric + 2' + any extra
needed.
Per size $0.23
5 Fabric and roller assemblies include #2, 3 and 4
HDTV (16:9) Format
99548 Fabric and roller assy., Da-Mat 92" x 164" - 188" diag. 1 $2,543.00
99553 Fabric and roller assy., Da-Tex 92" x 164" - 188" diag. 1 $2,902.00
99554 Fabric and roller assy., HD Progressive ReView 0.9 92" x 164" - 188" diag. 1 $3,086.00
99671 Fabric and roller assy., Da-Mat 108" x 192" - 220" HD diag. 1 $3,013.00
99676 Fabric and roller assy., Da-Tex 108" x 192" - 220" HD diag. 1 $3,359.00
99677 Fabric and roller assy., HD Progressive ReView 0.9 108" x 192" - 220" HD diag. 1 $3,657.00
36809 Fabric and roller assy., Da-Mat 121" x 216" - 247" diag. 1 $4,076.00
36814 Fabric and roller assy., Da-Tex 121" x 216" - 247" diag. 1 $4,505.00
36815 Fabric and roller assy., HD Progressive ReView 0.9 121" x 216" - 247" diag. 1 $4,946.00
36816 Fabric and roller assy., Da-Mat 135" x 240" - 275" diag. 1 $4,479.00
36821 Fabric and roller assy., Da-Tex 135" x 240" - 275" diag. 1 $4,918.00
36822 Fabric and roller assy., HD Progressive ReView 0.9 135" x 240" - 275" diag. 1 $5,436.00
36823 Fabric and roller assy., Da-Mat 146" x 260" - 298" diag. 1 $4,730.00
36828 Fabric and roller assy., Da-Tex 146" x 260" - 298" diag. 1 $5,086.00
36829 Fabric and roller assy., HD Progressive ReView 0.9 146" x 260" - 298" diag. 1 $5,740.00
Video (4:3) Format
99589 Fabric and roller assy., Da-Mat 108" x 144" - 180" diag. 1 $2,060.00
99594 Fabric and roller assy., Da-Tex 108" x 144" - 180" diag. 1 $2,693.00
99596 Fabric and roller assy., Da-Mat 120" x 160" - 200" diag. 1 $2,680.00
99601 Fabric and roller assy., Da-Tex 120" x 160" - 200" diag. 1 $2,962.00
99534 Fabric and roller assy., Da-Mat 126" x 168" - 210" diag. 1 $2,899.00
99539 Fabric and roller assy., Da-Tex 126" x 168" - 210" diag. 1 $3,257.00
99541 Fabric and roller assy., Da-Mat 132" x 176" - 220" diag. 1 $3,117.00
99546 Fabric and roller assy., Da-Tex 132" x 176" - 220" diag. 1 $3,480.00
99664 Fabric and roller assy., Da-Mat 144" x 192" - 240" diag. 1 $3,345.00
99669 Fabric and roller assy., Da-Tex 144" x 192" - 240" diag. 1 $3,731.00
36802 Fabric and roller assy., Da-Mat 162" x 216" - 270" diag. 1 $4,206.00
36807 Fabric and roller assy., Da-Tex 162" x 216" - 270" diag. 1 $3,856.00
6 83501 Screw for roller bracket 8 $0.60
7 83010 Roller bracket, pin end 1 $16.55
83017 Bearing, flange 1 $50.00
8 99974 Wood box assy. For 180" diag. screens 1 $1,410.00
99976 Wood box assy. for 210" diag. screens 1 $1,678.00
99978 Wood box assy. for 240" diag. screens 1 $1,745.00
99975 Wood box assy. for 200" diag. screens 1 $1,546.00
99977 Wood box assy. for 220" diag. screens 1 $1,715.00
35623 Wood box assy. for 270" diag. screens 1 $1,817.00
99979 Wood box assy. for 188" diag. screens 1 $1,678.00
99980 Wood box assy. for 220" HD diag. screens 1 $1,745.00
35624 Wood box assy. for 247" diag. screens 1 $1,771.00
35625 Wood box assy. for 275" diag. screens 1 $1,932.00
