63
DL–0645 (Rev. 4) 07.21
© 2021 Legrand AV Inc.
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
13 35907 Screws to attach the end caps 8 $0.80
14 35885 Pin end cap assy. 1 $58.50
15 35888 Door bracket assy. 2 $7.80
16 80874 Nut to attach bracket assy. 4 $0.32
17 37390 Aluminum white case for 14' and 210" diag. screens 1 $6,000.00
70755 Aluminum white case for 208" diag. screens 1 $6,000.00
37391 Aluminum white case for 16', 240" diag., 216" diag. and 222" diag. screens 1 $6,000.00
37392 Aluminum white case for 18', 265" diag. and 243" diag. screens 1 $7,500.00
37393 Aluminum white case for 20', 295" diag. and 271" diag. screens 1 $7,500.00
37394 Aluminum white case for 22' screens 1 $7,500.00
37395 Aluminum white case for 24' screens 1 $7,500.00
18 35882 Hanger bracket 5-7 $10.25
19 38040 Bolt for hanger brackets 10-14 $1.70
38041 Nut for hanger brackets 10-14 $0.49
44842 Washer for hanger brackets 10-14 $0.35
20 35914 Junction box 1 $13.25
35915 Junction box cover 1 $2.30
21 94082 Screws to attach the junction box cover 2 $0.16
22 21264 PCB and housing assy., 120v 1 $100.00
38037 PCB and housing assy., 120v for screens with LVC 1 $326.00
39280 PCB and housing assy., 120v for screens with SCB100 1 $656.00
21266 PCB and housing assy., 240v 1 $100.00
32739 PCB and housing assy., 240v for screens with LVC 1 $326.00
32763 PCB and housing assy., 240v for screens with SCB100 1 $656.00
23 35883 Motor end cap assy. 1 $48.70
24 39875RPL Motor assy., 120v for 5.75" roller 1 $585.00
35927RPL Motor assy., 120v for 7" roller 1 $681.00
32767RPL Motor assy., 230v for 5.75" roller 1 $585.00
32740 Motor assy., 240v for 7" roller 1 $681.00
25 35916 Roller bracket, motor end for 5.75" roller 1 $20.85
35880 Roller bracket, motor end for 7" roller 1 $20.85
26 37866 Motor bracket 1 $7.00
27 38739 Bolt to attach the motor bracket to the roller bracket 1 $0.75
44753 Nut to attach the motor bracket to the roller bracket 1 $0.27
28 40975 3-Button switch-LVC, white (not shown) 1 $101.00
