91
DL-0652 (Rev. 4) 07.21
© 2021 Legrand AV Inc.
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number Description
Quantity
Required
List Price
Each
10 83699 Ironing board for 14', 210" diag. and 188" diag. screens 1 $101.00
83718 Ironing board for 16', 240" diag. and 216" diag. screens 1 $107.00
83719 Ironing board for 18' and 243" diag. screens 1 $117.00
83720 Ironing board for 20' and 271" diag. screens 1 $119.00
83382 Ironing board for 24' screens 1 $124.00
11 44777 Screw for ironing board bracket 5-9 $0.16
12 83010 Roller bracket assy., right for 50"-18' screens 1 $16.55
89038 Roller bracket assy., right for 20'-24' screens 1 $17.55
83017 Bearing, flange 1 $50.00
83017 Bearing, flange 1 $50.00
13 44711 Retaining ring 2 $0.35
14 46559 Key for lovejoy coupling 2 $1.35
15 70937 Lovejoy coupling, black for under 20' screens 1 $29.20
----- Lovejoy coupling, blue for 20' and over screens - No longer available 1 -----
16 76257 Spider for lovejoy coupling, black for under 20' screens 1 $9.90
91635 Spider for lovejoy coupling, blue for 20' and over screens 1 $23.00
17 46565 Motor shaft, drive 1/2" diam. 1 $24.85
18 83966 Limit switch set 1 $117.00
19 ----- Junction box 1 -----
20 91175 Junction box cover 1 $2.65
21 89664 Capacitor, 25 MFD 120v for 50"-18' screens 1 $132.00
91901 Capacitor, 30 MFD 120v for 20'-24' screens 1 $200.00
90536 Capacitor, 8 MFD for 240v 1 $107.00
22 79678 Lovejoy coupling retainer 1 $2.80
23 72537 Screws for lovejoy coupling retainer 2 $0.32
24 46354 Universal hanger bracket, front for 50" - 20' screens (not shown) 3 $13.15
46354 Universal hanger bracket, front for 24' screens (not shown) 4 $13.15
46356 Front hanger bracket for 50"-18' screens (not shown) 3 $20.40
46358 Back hanger bracket for 50"-18' screens (not shown) 3 $11.70
88786 Front hanger bracket for 20' screens (not shown) 3 $22.45
88788 Back hanger bracket for 20' screens (not shown) 3 $13.65
88786 Front hanger bracket for 24' screens (not shown) 4 $22.45
88788 Back hanger bracket for 24' screens (not shown) 4 $13.65
59159 Hardware for hanger brackets for 50" - 20' screens (not shown) 1 $4.60
39863 Hardware for hanger brackets for 24' screens (not shown) 2 $4.60
Note: In the event the complete hangers and hardware are to be ordered, order as follows:
59155 Hangers and hardware for 50"-18' screens (not shown) 1 $92.10
89270 Hangers and hardware for 20' screens (not shown) 1 $101.00
39862 Hangers and hardware for 24' screens (not shown) 2 $101.00
25 80575 Wall switch, 120v white (not shown) 1 $77.00
40961 Wall switch, 120v ivory (not shown) 1 $77.00
11147 Wall switch, 240v white double push putton (not shown) 1 $77.00
38463E Wall switch, 240v white rocker (not shown) 1 $77.00
