Ascender Electrol
E: [email protected] | P: 1-800-622-3737 | F: 1-877-325-4832
Diagram
Number
Da-Lite
Number
Description
Quantity
Required
List Price
Each
1
85481
Case for 100" diag., 120" diag., 106" diag. and 119" diag. screens
1
$1,633.00
85487
Case for 150" diag. and 159" diag. screens
1
$2,178.00
85491
Case for 180" diag. and 200" diag. screens
1
$2,308.00
85483
Case for 133" diag. screens
1
$1,814.00
2
86762
Hinge for lid
Per Size
$36.10
3
85482
Lid for 100" diag., 120" diag., 106" diag. and 119" diag. screens
1
$1,994.00
85488
Lid for 150" diag. and 159" diag. screens
1
$2,376.00
85492
Lid for 180" diag. and 200" diag. screens
1
$2,638.00
85484
Lid for 133" diag. screens
1
$2,094.00
4
85265
Arm mounting bracket
3
$65.80
5
85266
Support tube shaft
2
$44.10
6
85584
Support tube for 100" diag., 120" diag., 106" diag. and 119" diag. screens
1
$150.00
85588
Support tube for 150" diag. screens
1
$150.00
85591
Support tube for 180" diag. screens
1
$150.00
36388
Support tube for 200" diag. screens
1
$152.00
85586
Support tube for 133" diag. screens
1
$150.00
85589
Support tube for 159" diag. screens
1
$150.00
7
87515WHITE Arm guide bracket
2
$9.15
8
85575
Arm rest bracket
4
$3.30
9
85577
Upper left spring bracket
1
$23.35
10
85261
Arm for 100" diag., 120" diag., 106" diag., 119" diag. And 133" diag. Screens
1 pair
$1,946.00
85262
Arm for 150" diag. and 159" diag. screens
1 pair
$2,104.00
85263
Arm for 180" diag. screens
1 pair
$2,220.00
36385
Arm for 200" diag. screens
1 pair
$2,298.00
11
Fabric and roller assembly
HDTV (16:9) Format
86781
Fabric and roller assy., Matte White 52" x 92" - 106" diag.
1
$735.00
86785
Fabric and roller assy., Matte White 58" x 104" - 119" diag.
1
$807.00
86789
Fabric and roller assy., Matte White 65" x 116" - 133" diag.
1
$919.00
86793
Fabric and roller assy., Matte White 78" x 139" - 159" diag.
1
$1,076.00
Video (4:3) Format
86765
Fabric and roller assy., Matte White 60" x 80" - 100" diag.
1
$672.00
86769
Fabric and roller assy., Matte White 69" x 92" - 120" diag.
1
$576.00
86773
Fabric and roller assy., Matte White 87" x 116" - 150" diag.
1
$962.00
86776
Fabric and roller assy., Matte White 105" x 140" - 180" diag.
1
$1,320.00
39690
Fabric and roller assy., Matte White 120" x 160" - 200" diag. (after 8-20-07)
1
$1,511.00
12
85596
Slat for 100" diag. screens
1
$119.00
85597
Slat for 120" diag. and 106" diag. screens
1
$120.00
89066
Slat for 150" diag. and 133" diag. screens
1
$124.00
85606
Slat for 180" diag. screens
1
$137.00
89067
Slat for 200" diag. screens
1
$234.00
85600
Slat for 119" diag. screens
1
$119.00
85605
Slat for 159" diag. screens
1
$137.00
13
70653
Motor assy. and hardware, 120v (includes #14)
1
$604.00
32768
Motor assy. and hardware, 240v (includes #14)
1
$604.00
33287
Drive wheel/rubber mount for screens purchased before 1/22/04 (not shown)
1
$40.00
14
37866
Universal bracket
1
$7.00
