YASNAC PCNC Operating Manual
APPENDIX 3: Parameter Tables
Spindle
Address
Bit
Description
Register
Units
Minimum
Value
Maximum
Value
Long Description
1000
2
Override setting on spindle
speed output
0
1
4
Filter for spindle load and speed
0
1
Filtering in the I/O
output for the spindle
load and speed moni-
tor
1002
0
Magnification ratio of spindle
speed parameter
0
1
1026
0
1st spindle YENET number
0
15
No.1 physical spindle
5
1st spindle debug mode
0
1
YENET1200 station
number setting (No. 2
to No. 15 station)
6
1st physical spindle specifica-
tions
0
1
7
1st physical spindle enable
0
1
1039
1
Spindle servo control type
0
2
5
Spindle servo control enable
0
1
7
Spindle servo control configura-
tion
0
1
1091
0
Spindle encoder type
0
255
1127
Spindle display name
ascii
0
255
1169
Spindle automatic system axis
name
ascii
0
255
1400
Minimum spindle revolution
clamp for gear 1
r/min
0
30000
1401
Minimum spindle revolution
clamp for gear 2
r/min
0
30000
1402
Minimum spindle revolution
clamp for gear 3
r/min
0
30000
1403
Minimum spindle revolution
clamp for gear 4
r/min
0
30000
1404
Maximum spindle revolution
clamp for gear 1
r/min
0
30000
1405
Maximum spindle revolution
clamp for gear 2
r/min
0
30000
1406
Maximum spindle revolution
clamp for gear 3
r/min
0
30000
1407
Maximum spindle revolution
clamp for gear 4
r/min
0
30000
1408
Spindle max motor speed for
gear 1
r/min
0
30000
1409
Spindle max motor speed for
gear 2
r/min
0
30000
