Connecting to a Wireless LAN by Using the Router
Button (Push Button Mode)
94LS-01A
If your wireless LAN router supports WPS push button mode, you can easily set up a connection simply by using the
operation panel of the machine and the button on the wireless LAN router.
Administrator privileges are required to connect to a wireless LAN.
Touch Panel Model(P. 58)
5 Lines LCD Model(P. 59)
Touch Panel Model
1
On the operation panel, press [Wireless LAN Set.] in the [Home] screen. [Home]
Screen(P. 113)
➠ The [Select Network] screen is displayed.
● If the login screen appears, enter the System Manager ID and PIN, and then press [Log In]. System
Manager ID and PIN(P. 5)
● If the message [Enable the wireless LAN?] appears, press [Yes].
● If the message [Cannot find the access point.] appears, press [Close].
2
Press [Other Connections].
3
Press [WPS Push Button Mode].
➠ The machine starts searching for an access point.
4
After the search for an access point starts, press the button on the wireless LAN
router within two minutes.
Press the button within two minutes. (Depending on the wireless LAN router, you may have to press and hold
the button.)
* For details on how to operate the button, see the manual of your wireless LAN router.
5
When [Connected.] appears on the operation panel, press [Close].
➠ When the machine is connected to the wireless LAN, [ ] appears on the [Home] screen.
6
Wait a few minutes.
➠ By default, an IP address is set automatically.
To use a specific IP address, set this manually.
Setting IPv4 Addresses(P. 71)
Setting IPv6 Addresses(P. 75)
