6-1
Chapter 6. Modem Type
6.1 Modem
Types
Refer to Table 6-1 for configuring the modem to the following types of operation. Each
type allows the user to operate the modem under the requirements of the configuration
specifications listed below.
Table 6-1. Modem Types
Configuration
Specification
IDR ( Intermediate Data Rate)
IESS-308
IBS (INTELSAT Business Service)
IESS-309, Legacy EFD equipment when RS=ON,
K/N =112/126
VSAT IBS
INTELSAT compliant mode with NO Overhead and
RS = 201/219
D&I (Drop & Insert)
IESS-308-5
ASYNC
Asynchronous Overhead, including AUPC
AUPC
AUPC on Reed-Solomon Card, No Async
EFD Closed
Network
Custom
Access all modes
CDM
Comtech EF Data Compatible
Emulation Types
Specifications
SDM-100
Emulates SDM-100 remote protocol
SDM-6000
Emulates SDM-6000 remote protocol
Revision Emulation
Emulates earlier released software remote protocol
