medSim 300B
Operators Manual
3-10
To access page 3, as shown below, press the <right arrow> key again (pressing the <left
arrow> returns you to page 1 of the FUNCTION SELECT MENU):
FUNCTION SELECT
<
UTIL
<F1>
<F2>
<F3>
<F4>
eic009.eps
Function Select - ECG Menu
1. To choose the ECG MENU, return to the first page of the FUNCTION SELECT
MENU and press <F1>-ECG.
2. The ECG MENU choices are presented on two pages as illustrated below. Again,
use the <left arrow> and <right arrow> keys to access the six ECG function
selections.
ECG
PERF
BASE
ARRH
PVC
>
<F1>
<F2>
<F3>
<F4>
eic010.eps
ECG
<
PACE
INS
<F1>
<F2>
<F3>
<F4>
eic011.eps
Note
Illustrations may not match your medSim 300B display if additions, options,
or expansion modules have been installed.
