24-5
z
RFC 1723 only defines plain text authentication. For information about MD5 authentication, refer to
RFC2082 “RIPv2 MD5 Authentication”.
z
With RIPv1, you can configure the authentication mode in interface view. However, the
configuration will not take effect because RIPv1 does not support authentication.
Supported RIP Features
The current implementation supports RIPv1 and RIPv2
Protocols and Standards
RFC 1058: Routing Information Protocol
RFC 1723: RIP Version 2 - Carrying Additional Information
RFC 1721: RIP Version 2 Protocol Analysis
RFC 1722: RIP Version 2 Protocol Applicability Statement
RFC 1724: RIP Version 2 MIB Extension
RFC 2082: RIPv2 MD5 Authentication
Configuring RIP Basic Functions
Configuration Prerequisites
Before configuring RIP basic functions, configure IP addresses for interfaces, making all adjacent
nodes reachable to each other at the network layer.
Configuration Procedure
Enabling RIP and a RIP interface
Follow these steps to enable RIP:
To do…
Use the command…
Remarks
Enter system view
system-view
––
Enable a RIP process and enter
RIP view
rip
[ process-id ]
Required
Not enabled by default
Enable RIP on the interface
attached to the specified network
network network-address
Required
Disabled by default
