User’s Manual of WGS3-2820/WGS3-5220
508
Interface Valid unit, slot and port number separated by forward slashes.
Group Compatibility Mode The group compatibility mode (v1, v2 or v3) for the specified group on this interface.
Source Filter Mode The source filter mode (Include/Exclude) for the specified group on this interface. This is
“-----” for IGMPv1 and IGMPv2 Membership Reports.
Source Hosts This displays the list of unicast source IP Addresses in the group record of the IGMPv3
Membership Report with the specified multicast group IP Address. This is “-----” for
IGMPv1 and IGMPv2 Membership Reports.
Expiry Time This displays the amount of time remaining to remove this entry before it is aged out. This
is “----” for IGMPv1 and IGMPv2 Membership Reports.
13.3.19 show ip igmp interface stats
This command displays the IGMP statistical information for the given interface. The statistics are only displayed when the
interface is enabled for IGMP.
▫ Format show ip igmp interface stats <unit/slot/port>
▫ Modes Privileged EXEC User EXEC
Querier Status This field indicates the status of the IGMP router, whether it is running in Querier mode or
Non-Querier mode.
Querier IP Address This field displays the IP Address of the IGMP Querier on the IP subnet to which this
interface is attached.
Querier Up Time This field indicates the time since the interface Querier was last changed.
Querier Expiry Time This field displays the amount of time remaining before the Other Querier Present Timer
expires. If the local system is the querier, the value of this object is zero.
Wrong Version Queries This field indicates the number of queries received whose IGMP version does not match
the IGMP version of the interface.
Number of Joins This field displays the number of times a group membership has been added on this
interface.
Number of Groups This field indicates the current number of membership entries for this interface
