SMS command separator:
This parameter specifies the character to be used to separate multiple command lines when a
remote SMS sender is controlling the unit. The default separator is <CR><LF> but some SMS
capable devices are not equipped with <CR> and <LF> keys so an additional means of separat-
ing multiple lines is required.
SMS access level:
The access level for SMS commands. The access level set here will need to match the level
required by the command sent by SMS for the command to be accepted.
SMS Replies:
This parameter enables or disables replies to SMS commands.
SMS concatenation limit:
This parameter concatenates replies to SMS commands, thereby limiting the number of mes-
sages sent. A value of 1 (default) means no concatenation. Zero means no limit, which at present
means the first 1500 bytes of a command response (i.e. 10 messages).
Enable Mux / Disable Mux:
The two buttons at the bottom of the page labelled Enable Mux and Disable Mux are used to
enable or disable 0710 multiplex mode for the wireless module. When this mode is enabled
(which it is by default), several additional parameters become effective on the Configure >
ISDN LAPB page under the heading “Async Mux 0710 Parameters”. Refer to the description of
this page for further information.
Using Text Commands
From the command line, the modemcc command can be used to configure the wireless module. To
display the current settings for the wireless module enter the command:
modemcc <instance> ?
where <instance> is 0. To change the value of a parameter use the same command in the for-
mat:
modemcc 0 <parameter> <value>
The parameters and values are:
Parameter Values Equivalent Web Parameter
apn text APN
att_interval number Minimum attach interval (secs)
buapn text Back-up APN
buipaddr IP address Backup static IP address
check_reg 0,1,2 Power cycle on loss of registration:
0=Never
1=GSM only
2=GPRS only
epin text None - This is the PIN in encrypted format. This
parameter is not con figurable.
hang_str text Hang-up string
init_str text Initialisation string 1
init_str1 text Initialisation string 2
init_str2 text Initialisation string 3
ipaddr IP address Static IP address
link_retries number Link retries
pin number PIN
