HEIDENHAIN CNC PILOT 4290 317
6.13 A
u
tomatic W
o
rking Plan Gener
ation (A
WG)
Main machining Submachining Location Execution
Drilling – continued
Centering, drilling,
Countersinking, reaming,
tapping (*) Location Machining a bore hole on the selected machining location
*: Define the drilling cycle
Drilling combinations:
■ Define the drilling combinations as
machining attributes (see ” 6.9.6 Machining
Attributes”).
■ Select the appropriate drilling operation as
submachining operation (see above).
Milling Contour analysis: Determining the milling contour.
Sequence – milling operation:
■ Linear and circular slots
■ Open contours
■ Closed contours (pockets), single surfaces and
polygonal surfaces
Sequence – machining location:
■ Front face (also machines front face in Y)
■ Lateral surface (also machines lateral surface in Y)
– then sequence of geometrical definition
– – Execution of all milling operations on all machining
locations
Surface, contour, slot,
pocket (*) – Execution of the selected milling operation on all
machining locations
Surface, contour, slot,
pocket (*) Location Execution of the selected milling operation on the
selected machining location
*: Define the type of contour
