Section Five:Image Mobility Image Manipulation
2. Enter the image index number for the image you wish to retrieve.
Only the number is to be entered. The prefix of the file is determined by the
settings in the Image File dialog(see Figure 3-18: File Defaults dialog, on page 47). If
you have changed the prefix setting in order to help group files for a particular
purpose, make sure the prefix in the Image File dialog matches the prefix of the file
you are attempting to retrieve.
The file extension must be “bmp”.
The image is displayed on the screen.
Printing Images
The CPN-5000 allows you to print to a color Postscript printer either directly or
over a TCP/IP network. If you print directly, the configuration requires a USB to
Centronics cable. Contact Boeckeler Instruments if you want to use a direct
connection. To print over a TCP/IP network requires an ethernet cable and the
address of the printer (see Printer Setup, on page 63).
To print an image
1. Print an image in one of the following ways:
a) Activate the “Print” button on the digital tablet,
b) Type “Alt-F4” on your keyboard,
c) Touch the Center-Right command button on the touch screen.
2. The image is sent to the printer.
A counter appears at the lower-right portion of the screen, indicating the percent-
age of the image sent to the color Postscript printer.
When the counter reaches 100, it disappears. The system is then ready to print
another image.
Sending Images
The CPN-5000 allows you to send images to other CPN-5000’s over a TCP/IP
network. All units must be currently active in the same Multipoint meeting (see
Multipoint, on page 64)
