Page 78 - Pointmaker CPN-5000 Color Video Marker Boeckeler Instruments, Inc.
Assigning Marker Appearance Section Four: Using Markers
Selecting Pointers
You select a pointer type while the pointer is active, or positionable. After you
anchor the pointer, you cannot change that pointer’s type. However, you can erase
or undo the anchored pointer and begin again (see Erasing Markers, on page 88).
From the Digitizing Tablet
1. Click the pen tip on the desired pointer icon on tablet.
The corresponding active pointer appears on screen, ready for posi tioning or
anchoring.
From the Keyboard
1. Repeatedly activate the POINTERS command until the desired pointer
type appears on screen.
You can scroll backwards through the pointer options, by activating the
Reverse Toggle command.
The pointer you selected appears on screen, ready for positioning.
From the Menu System
1. Activate the menu system (see Activating the Menu, on page 27).
The Main Menu appears (see Figure 3-1, Main Menu, on page 28).
2. Select the ANNOTATION option
The Annotation menu appears (see Figure 3-3, Annotation Menu, on page 32).
3. Select the POINTERS option.
