Overview Section Six:Using RS-232 Commands
(CPN) Read Image From TFTP
The “CPN” command reads an image from the TFTP server. This com mand uses
the current Directory and Prefix assigned for capturing images. The nnnnn part of
the command also automatically sets the index number (see “Captured Image File
Setting” on page 40).
<Esc>(CPNnnnnn Read the requested image
nnnnn is the index number of the image
(CPP) Print Current Image
The “CPP” command prints the current image.
<Esc>(CPP Print the current image
(CPRD) Read Current Image
The “CPRD” command reads the current image based on the current Capture
Image File settings (see “Captured Image File Settings” on page 40).
<Esc>(CPRD Read the current image
(CPSD) Store Current Image
The “CPSD” command stores the current image based on the current Capture
Image File settings.
<Esc>(CPSD Store the current image
