Overview
Section Six:Using RS-232 Commands
(CE) Color Enable
The “CE” command determines what colors are available from the color pal ette.
Refer to the “CS” commands for how to change the color of a marker using this
enabled palette.
<Esc>(CEB1
Enable Black
<Esc>(CEBØ
Disable Black
<Esc>(CEC1
Enable Cyan
<Esc>(CECØ
Disable Cyan
<Esc>(CEG1
Enable Green
<Esc>(CEGØ
Disable Green
<Esc>(CEHG1
Enable Green Highlight
<Esc>(CEHGØ
Disable Green Highlight
<Esc>(CEHP1
Enable Pink Highlight
<Esc>(CEHPØ
Disable Pink Highlight
<Esc>(CEHY1
Enable Yellow Highlight
<Esc>(CEHYØ
Disable Yellow Highlight
<Esc>(CEP1
Enable Pink
<Esc>(CEPØ
Disable Pink
<Esc>(CER1
Enable Red
<Esc>(CERØ
Disable Red
<Esc>(CEW1
Enable White
<Esc>(CEWØ
Disable White
<Esc>(CEY1
Enable Yellow
<Esc>(CEYØ
Disable Yellow
(CL) Clear
The “CL” command clears the markers from the video overlay.
<Esc>(CL
Clears All Markers
