Pointmaker CPN-5000 Color Video Marker - Page 21
Section Two:Installation
General Installation
Power Up
These are the procedures for powering up.
1. Plug the power cord into the back of the Pointmaker and then into any
grounded outlet.
2. Plug the power cords from any video source(s), controller(s), and
display(s) into any grounded outlet.
3. Turn on each of the connected units, and then press the power button on
the front panel of the Pointmaker.
NOTE: In order for the Pointmaker to properly sync with the video signals, the
sources should be turned on first.
After a moment, a Pointmaker splash screen will appear, followed by the initializ-
ing of the ports, and ending with a copyright message.
After the startup process, a marker overlay will appear, displaying any previously
created markers.
If this process is different for you, recheck your installation and power up again.
Call Boeckeler Instruments for support at (800) 552-2262 or (520) 745-0001 if it
is still unsuccessful.
NOTE: To bypass port initialization, press ESC during startup.
