Section Six:Using RS-232 Commands Overview
(B) Background
The “B” command tells the Pointmaker which background to use.
<Esc>(BV
Video Background
<Esc>(BC
Chalkboard Background
<Esc>(BT
Video/Chalkboard Toggle
<Esc>(BL1
Display Text Background (on text and date/time labels)
<Esc>(BLØ
No Text Background (on text and date/time labels)
<Esc>(BLT
Toggle Text Background (on text and date/time labels)
(CA) Calibrations
The “CA” command assigns a calibration to a selected COMM port.
<Esc>(CA0pnn
Port “p” has calibration “nn” assigned to it
p is a numeric value of 0-9 designating COMM ports 1-10
nn is a numeric value 1-10 designating calibrations 1-10
. Examples:
<Esc>(CA0004
Utilize Cal #4, Port 1
<Esc>(CA0505
Utilize Cal #5, Port 6
<Esc>(CA0806
Utilize Cal #6, Port 9
(CD) Calibration Types
The “CD” command activates a calibration procedure.
<Esc>(CDP
Activate USB PVI-PC20 calibration.
<Esc>(CDT
Activate Touchscreen calibration.
<Esc>(CDW
Activate Whiteboard calibration.
