Pointmaker CPN-5000 Color Video Marker - Page 15
Section Two:Installation
General Installation
G
eneral
i
nstallation
Installation of the Pointmaker CPN-5000 can be divided into the following three areas:
• Connect Video Sources and Displays (for composite, S-Video, DVI, VGA)
• Connect Controllers
• Power Up (leaving the CPN-5000 to last)
Connecting Video Sources and Displays
For connecting video sources, the CPN-5000 supports composite video , Y/C (S-Video),
DVI-I, and HDMI. For connecting video displays, there is support for DVI-I and HDMI.
Composite or Y/C (S-Video) Connectors
The video inputs on the CPN-5000 support a pair of composite and a pair of Y/C (S-Video).
NOTE: Make all connections before applying power.
If connecting Composite video:
1. Using a BNC cable, connect a Pointmaker COMPOSITE INPUT connec tor to the
video output connector on a composite video source. You can repeat this process
with the second COMPOSITE INPUT connector.
HDMI Out SPDIF Out
DVI-I Out
Network
Keyboard
USB
COMM. 1
COMM. 2
Power
DVI-I 1 In
VGA In
Comp 1 /
Y In
Comp 2 /
C In
DVI-I 2 In
HDMI In
+24VDC
2.5A
1
2
Figure 2-1: Composite Connectors
If connecting Y/C (S-Video):
1. Using a Y/C BNC cable, connect the two Pointmaker Y/C INPUT connectors to a
video output connector on a Y/C video source.
