Overview
Section Six:Using RS-232 Commands
(PX) Proximity On/Off
The “PX” command controls the pen proximity feature of digitizing tablets. When
proximity is on, active pointers disappear when the pen is lifted from the drawing
area. When proximity is off, active pointers remain on-screen when the pen is
lifted.
<Esc>(PX1
Turn proximity on.
<Esc>(PXØ
Turn proximity off.
<Esc>(PXT
Toggle proximity.
(R) Restart Pointmaker
The “R” command restarts the Pointmaker. Options include saving current
set tings and markers in memory (a soft boot), or clearing memory of all settings
and markers (a hard boot).
<Esc>(RS
Restart saving current settings and markers in memory.
<Esc>(RH
Restart clearing current settings and markers.
(S) Date/Time Marker
The “S” command controls options concerning the date/time marker. It dis plays as
an active marker.
<Esc>(STØ
Displays date/time marker in time only mode.
<Esc>(SDØ
Displays date/time marker in date only mode.
<Esc>(SDT
Displays date/time marker in time only mode.
<Esc>(SDSMMDDYYYY
Set the date.
M=month, D=Day, Y=year
<Esc>(STAHHMM
Set time as a.m.
H=hour, M=minute
<Esc>(STPHHMM
Set time as p.m.
H=hour, M=minute
