Section Three:CPN-5000 Menu System Preparing the CPN-5000 for Use
3. Select USB DEVICES.
G r a p h i r e 4 x 5
N o D e v i c e
?
?
N o D e v i c e ?
N o D e v i c e ?
N o D e v i c e ?
N o D e v i c e ?
N o D e v i c e ?
N o D e v i c e ?
N o D e v i c e ?
N o D e v i c e ?
1
2
3
4
5
6
7
8
9
1 0
USB DEVICES
Figure 3-28: USB Devices Dialog
The USB Devices dialog appears.
Up to 10 USB devices can be connected through the use of hubs.
NOTE: All the USB devices installed on your CPN-5000 are listed by
port number, with the device type displayed to the right of each number.
If the device type is in blue, it has been assigned through the autodetect
procedure at startup.
NOTE: When the question mark to the right of the device is selected,
the system displays the vendor and product ID for the device.
4. (optional) Select the device type you wish to have permanently assigned.
By selecting the device, it becomes permanently assigned. The text color then
changes from blue to black. With the device permanently assigned, the next
time the CPN-5000 is powered up, the autodetect procedure will skip this
device.
The system does an excellent job of immediately detecting and rec ognizing
USB devices, even when their position on the hub changes. There are two
instances where you might want to permanently assign a device type to a
device (so autodetect won’t try to re-assign it at the next boot-up): 1) if the
device was marketed after your CPN-5000 system was manufactured or 2) if
the system misidentifies the device.
