Overview
Section Six:Using RS-232 Commands
1280 x 720P @ 60 Hz
17
1920 x 1080P @ 60 Hz
18
1280 x 800 @ 60 Hz
19
1440 x 900 @ 60 Hz
20
1680 x 1050 @ 60 Hz
21
1400 x 1050 @ 50 Hz
22
1400 x 1050 @ 60 Hz
23
(SCP) Video Output Sync Polarity
The “SCP” command controls the horizontal sync polarity and vertical sync
polarity of the video output.
<Esc>(SCPHD
Default HS polarity
<Esc>(SCPHD
Negative HS polarity
<Esc>(SCPHD
Positive HS polarity
<Esc>(SCPVD
Default VS polarity
<Esc>(SCPVD
Negative VS polarity
<Esc>(SCPVD
Positive VS polarity
(SCR) Scaler Reinitialize
The “SCR” command reinitializes the scaler. It’s recommended to try the auto
adjust(SCA) first.
<Esc>(SCR
Reinitializes the scaler
(SUM) Menu System
The “SUM” command displays the Main Menu.
<Esc>(SUM
Activate the menu system.
