Preparing the CPN-5000 for Use Section Three:CPN-5000 Menu System
Where a question mark is usually found, you will instead see an arrow.
NOTE: If the device type you desire for connecting to other systems is
unavailable, check to see if it is assigned to another port. Remem ber, only one
use of each is allowed.
2. Activate the arrow next to the device type to set its communication
parameters.
Control Port PORT #1
BAUD RATE PARITY STOP
BITS
9600
4800
2400
1200
600
300
110
NONE
EVEN
ODD
SPACE
MARK
RETURN
1
2
Figure 3-27: Control Port Dialog
The corresponding dialog appears.
Select the desired baud rate, parity, and stop bits.
NOTE: Factory settings are 9600 baud, no parity, 1 stop bit. Data bits, which
cannot be manually set, are 8 data bits.
3. Exit the menu system and cycle the power on the CPN-5000.
The CPN-5000 implements the new settings.
Designating a USB Device Type
1. Activate the menu system (see Activating the Menu, on page 27).
The Main Menu appears (see Figure 3-1: Main Menu, on page 28).
2. Select DEVICES.
The Devices menu appears (see Figure 3-19: Devices menu, on page 49).
