Pointmaker CPN-5000 Color Video Marker - Page 65
Section Three:CPN-5000 Menu System
Preparing the CPN-5000 for Use
MULTIPOINT SERVER
CONNECT >
PREVIOUS MENU >
10.0.1.3
10001
ADDR
PORT
Figure 3-34: Multipoint Network dialog
The Multipoint Server dialog appears.
The information entered into this dialog is technical and not usually under-
stood by the average user. You may need to acquire it from your IT depart-
ment or your ISP. It may help to make a copy of this page for them.
4. Enter the IP address of the computer acting as your Multipoint server.
Check with your IT administrator if you don’t know this address.
You may use our server at 67.19.240.122
5. Enter the Port number.
This is usually 10001. Our server’s port number is 10001.
6. Continue to the next section.
Create, Join or Exit a Multipoint Meeting
Once all the previous steps have been accomplished, the Pointmaker unit is ready
to support the Multipoint features. These steps explain how you can cre ate a
Multipoint meeting that other Multipoint enabled Pointmakers can join. We also
explain how you can join a Multipoint meeting that someone else has created.
Finally, we explain how to exit a meeting you have joined.
1. Select CONNECT.
