4. Select the OK button to return to the Display menu.
5. Exit the menu system.
VGA Output Sync
The CPN-5000 makes four different methods of syncing the VGA signal available
to you. You can also select none.
1. Activate the menu system
(see Activating the Menu, on page 27).
The Main Menu appears (see Figure 3-1: Main Menu, on page 28).
2. Select DISPLAY.
The Display menu appears (see Figure 3-6: Display Menu, on page 38).
3. Select the VGA OUTPUT SYNC option.
VGA OUTPUT SYNC
NONE
SYNC ON GREEN BILEVEL
SYNC ON GREEN TRILEVEL
SYNC ON ALL TRILEVEL
SYNC ON ALL BILEVEL
Figure 3-11: VGA Output Sync dialog
The VGA Output Sync dialog appears.
4. Select None or the output sync you desire.
5. Exit the menu system.
Video Color Space
The CPN-5000 allows you to set your video color space to RGB or YPbPr.
1. Activate the menu system
(see Activating the Menu, on page 27).
