Boeckeler Instruments, Inc. Pointmaker CPN-5000 Color Video Marker - Page 27
Section Three:CPN-5000 Menu System Using the CPN-5000 Menu System
u
sinG the
Cpn-5000 M
enu
s
ysteM
This section describes how to access the menu system and make selections from it.
Default User Settings
1. First, make your selections for the settings you wish to save.
2. Re-boot the unit using the CTRL-ALT-DEL key command or cycle the
power with the power switch.
3. When you see the Copyright screen during the boot process, press
CRTL-ALT-ENTER(on the number pad) to save your personal defaults.
The screen will acknowledge that the settings have been saved.
4. The settings can be recalled at any time by pressing CTRL-ALT-PgDn
(on the number pad).
Menu Basics
If the keyboard is installed, it is the only way you can enter the menu sys tem. If the
keyboard is not installed, you can access the menu system from one of the other
control devices.
Activating the Menu
Keyboard: Press Setup Menu[Print Screen] key.
Digitizing Tablet: Press and hold the Barrel Button, then the Tip Button on the
drawing area. Keep both pressed for about 10 seconds (works only if no keyboard
is connected).
NOTE: Press the tip button soon after the barrel button, or the CPN-5000
may interpret the barrel button press as a “clear” command.
