Overview
Section Six:Using RS-232 Commands
(E) Echo
The “E” command tells the Pointmaker to echo the input over the RS-232 link, in
full, in part or not at all.
<Esc>(EA
Echo all input
<Esc>(EC
Echo all except commands
<Esc>(EN
Disable echo
<Esc>(EO
Echo “OK” on command “OK <cr> <lf>”
(EM) Erase Method
The “EM” command activates your choice of erase methods.
<Esc>(
EM0
Erase Method: “UNDO”
<Esc>(
EM1
Erase using Small eraser
<Esc>(
EM2
Erase using Medium eraser
<Esc>(
EM3
Erase using Large eraser
(FS) Frame Size
The “FS” command defines an active frame.
<Esc>(FSXXXXYYYY
Designating the size of an active frame.
XXXX = a numeric value for the horizontal
dimension. YYYY = a numeric value for the vertical
dimension. Units range from ØØØ1 to 2Ø48.
