Page 62 -
Pointmaker CPN-5000 Color Video Marker
Boeckeler Instruments, Inc.
Preparing the CPN-5000 for Use
Section Three:CPN-5000 Menu System
Network Setup
1. Activate the menu system
(see Activating the Menu, on page 27).
The Main Menu appears (see Figure 3-1: Main Menu, on page 28).
2. Select the NETWORK option.
NETWORK
SETUP
PRINTER
MULTIPOINT
TFTP
Figure 3-31: Network Menu
The Network Menu appears.
3. Select the Setup option.
NETWORK SETUP
10.0.1.2
255.255.255.0
10.0.1.1
APPLY SETTINGS >
PREVIOUS MENU >
00:50:c2:6e:50:02
0.0.0.0
ADDR
NETMASK
GATEWAY
MAC:
CURRENT IP:
DHCP STATIC
Figure 3-32: Network Setup dialog w/sample data
The Network Setup dialog appears.
4. Select DHCP or STATIC.
