Section Three:CPN-5000 Menu System Preparing the CPN-5000 for Use
Calibrating CPN-5000 Controllers
You need to calibrate the touch screen on first installation. Calibration ensures an
intuitive and precise feel to drawing and marking over the particular moni tor you
are using.
NOTE: The calibration described in this section is the most accurate calibra-
tion for each touch screen connected to the CPN-5000. How ever, it is usually
necessary upon first power-up to do a rough calibra tion during the start-up
process. You can access this calibration through a short cut by touching the
copyright screen when it appears. The unit will activate the Touch Screen
Calibration dialog, with instructions for calibrating. This calibration is
accurate enough to operate the unit. You should then do the following
calibration proce dure to obtain the most accurate calibration.
Calibrations are automatically saved for each video port. If you move a touch
screen to a different port, run the calibration again. Or, if you have a touch screen
display with multiple video inputs, you should calibrate the touch screen for each
input.
All calibrations are stored in battery backed-up memory. The most recent cali-
bration will be recalled any time power is cycled off and on.
From the Menu System
1. Activate the menu system (see Activating the Menu, on page 27).
The Main Menu appears (see Figure 3-1: Main Menu, on page 28).
2. Select DEVICES
DEVICES
CALIBRATION
SERIAL PORTS
MULTIPLE
CONTROLLERS
PC TABLET SETUP
CONNECT MODEM
TABLET TEMPLATE
USB DEVICES
Figure 3-19: Devices menu
