Section Three:CPN-5000 Menu System Preparing the CPN-5000 for Use
CAPTURE
FILE DEFAULTS
DESTINATION USB TFTP
VERIFY ON OFF
Figure 3-17: Capture dialog
The Capture dialog appears.
3. Select FILE DEFAULTS.
FILE DEFAULTS
PVI
< PREVIOUS MENU
1
DIR
PREFIX
INDEX
Figure 3-18: File Defaults dialog
The File Defaults dialog appears.
4. In the DIR field, enter the directory name where you wish to save the file.
It must be 8 alphanumeric characters or less, no spaces and no subdi rectories.
5. In the PREFIX field, enter whatever letters you want each filename to
begin with.
The prefix must be 5 alphanumeric characters or less, no spaces.
6. In the INDEX field, enter the number to start numbering from.
Each time an image is saved, the number will increment. The num bering is
remembered by the CPN-5000, even through cycling of power.
Given the example shown, filenames will start with img1.bmp, then incre-
ment to img2.bmp, img3.bmp and so on.
7. Exit the dialog by selecting the Previous Menu button.
8. Exit the menu system.
