Pointmaker CPN-5000 Color Video Marker - Page 125
Section Six:Using RS-232 Commands Overview
(PA) Pass-through
The “PA” command enables the video image to “pass-through” the system without
displaying the marker overlay.
<Esc>(PA1
Enable pass-through. (overlay is hidden)
<Esc>(PAØ
Disable pass-through. (overlay is displayed)
<Esc>(PAT
Toggle pass-through.
(PT) Pointer Type
The “PT” command controls the display of pointer types contained in the
Pointmaker.
<Esc>(PTC
Displays Circle
<Esc>(PTDL
Display Down Left Arrow
<Esc>(PTDØ
Display Down Arrow
<Esc>(PTDR
Display Down Right Arrow
<Esc>(PTL
Display Left Arrow
<Esc>(PTN
Hide Pointer
<Esc>(PTP
Display Cross Hairs
<Esc>(PTR
Display Right Arrow
<Esc>(PTSC
Display Small Circle
<Esc>(PTSP
Display Small Cross Hairs
<Esc>(PTT1
Enable pointer toggle.
<Esc>(PTT2
Turn pointer off.
<Esc>(PTT3
Turn pointer on.
<Esc>(PTT4
Toggle pointer on/off.
<Esc>(PTT5
Display next pointer
selects next pointer in the sequence.
<Esc>(PTTØ
Disable pointer toggle.
<Esc>(PTUL
Display Up Left Arrow
<Esc>(PTUØ
Display Up Arrow
<Esc>(PTUR
Display Up Right Arrow
