Boeckeler Instruments, Inc.
Pointmaker CPN-5000 Color Video Marker - Page 37
Section Three:CPN-5000 Menu System
Preparing the CPN-5000 for Use
The Annotation menu appears (see Figure 3-3: Annotation Menu, on page 32).
3. Select the Enable Pointer Toggle option to turn it on or off.
NOTE: If the Enable Pointer Toggle button has a solid fill, it is active. If it is
not filled, it is inactive.
4. Exit the menu system.
Selecting Video Sources
The CPN-5000 starts in the DEFAULT mode, which automatically detects the
video inputs and outputs on power up. If multiple video sources are connected,
the source with the highest scan rate is given priority provided there is a dis play
that supports that source. Scan rate priority is: Y/C (NTSC or PAL), and compos-
ite (NTSC or PAL). Whatever video input is selected will be output to both video
outputs.
You can override the default selection by choosing a different video mode. If there
is an output, but no input, the CPN-5000 will display the chalkboard (see
Activating the Chalkboard, on page 91).
You can select a video mode from the tablet, keyboard, or menu system. The menu
system offers additional adjustments for brightness, contrast, saturation and hue.
From the Tablet
Click on the icon for the desired video input.
NOTE: The inputs are listed on the template.
The CPN-5000 swit ches to the source you select.
From the Keyboard
Activate the desired Video In command.
Refer to the keyboard commands for your desired input, located in the
Appendix (see Activating the Menu, on page 27).
The CPN-5000 switches to the source you select.
