Pointmaker CPN-5000 Color Video Marker - Page 127
Section Six:Using RS-232 Commands Overview
(SCA) Scaler Auto Adjust
The “SCA” command is used to force the scaler to auto adjust when artifacts are
present in the video signal. If artifacts are still present after issuing this command,
it is recommended to reinitialize the scaler(SCR).
<Esc>(SCA
Causes the scaler to auto adjust
(SCO) Scaler Output Format
The “SCO” command is used to set the scaler output to the desired format.
<Esc>(SCOnn
Seeting “nn” is the numeric value taken from the table
below to designate the format to be output by the scaler
Example: <Esc>(SCO09
640 x 480 @ 60 Hz
00
640 x 480 @ 72 Hz
01
640 x 480 @ 75 Hz
02
640 x 480 @ 85 Hz
03
800 x 600 @ 56 Hz
04
800 x 600 @ 56 Hz
05
800 x 600 @ 56 Hz
06
800 x 600 @ 56 Hz
07
800 x 600 @ 56 Hz
08
1024 x 768 @ 60 Hz
09
1024 x 768 @ 70 Hz
10
1024 x 768 @ 72 Hz
11
1024 x 768 @ 75 Hz
12
1024 x 768 @ 85 Hz
13
1280 x 1024 @ 60 Hz
14
1280 x 1024 @ 72 Hz
15
1280 x 1024 @ 75 Hz
16
